0470825 Fenner Drives Tango Link V Belting - Cross Section: B - 25ft - Beltsmart
Fenner Drives

0470825 by Fenner Drives | Tango Link V Belting | Cross Section: B | 25ft

Sale price$592.65
Fenner Drives - V Belting Conveying - Link V Belting

Package Quantity: 25 FT

Product Data:

Brand:
  • T-Link
Overview:
  • B/17 Tango Conveyor Belting offers many benefits over traditional polyurethane belting: No Welding; Easy, Fast Installation; Longer Belt Life; and Resistance to Harsh Environments.
Description:
  • Best Suited For: Conveying applications designed to use classical B/17 section polyurethane belts.

    Take advantage of the added-value benefits of Tango High Performance Conveyor Belting:

  • Easy, Fast Installation with No Welding Required
  • Make to length by hand, without tools
  • No curing time, just twist and go!


  • Longer Belt Life
  • Extremely high strength and excellent performance in harsh environments


    • Simple Inventory Management

  • Less money tied up in spare belting and no belt waste


    • From standard conveying to applications requiring abrasion resistance, non-marking, high temperature, oil and chemical resistance, you name it- simply Twist and Go with Tango Belting for all of your conveying needs.

    RoHS 2002/95/EC Directive compliant.

SPECIFICATIONS

Profile Shape: V Profile Size: B/17/5L
Reinforcement: None Color: Purple
Compliancy: RoHS Durometer: N/A
Material: N/A Package Length: 25ft

Part Number Material & Color Length Cross Section Minimum Pulley Ø Max Product Weight
w/Idlers		 Max Product Weight
w/UHMW
(in) (mm) (lbs) (kg) (lbs) (kg)
0470825 Tango Belting? 25ft B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0470833 Tango Belting? 10m B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0435101 PowerTwist® SuperGrip Top PU 100ft B 5.5" 140mm 400 lbs 181 kg 135 lbs 61 kg
0409200 PowerTwist® Super Grip Top PVC 100ft B 5.5" 140mm 400 lbs 181 kg 135 lbs 61 kg
0405082 PowerTwist® Friction Top® 25ft B 5.0" 127mm 400 lbs 181 kg 135 lbs 61 kg
0408082 PowerTwist® Friction Top® 100ft B 5.0" 127mm 400 lbs 181 kg 135 lbs 61 kg
0499021 PowerTwist® Bridge Top? 25ft B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0499002 PowerTwist® Bridge Top? 10ft B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0410300-25 PowerTwist® Roller Drive? 25ft B 5.0" 127mm 275 lbs 125 kg 95 lbs 43 kg
0410300 PowerTwist® Roller Drive? 100ft B 5.0" 127mm 275 lbs 125 kg 95 lbs 43 kg
0411301 PowerTwist® Roller Drive? 10m B 5.0" 127mm 275 lbs 125 kg 95 lbs 43 kg
0411300 PowerTwist® Roller Drive? 30m B 5.0" 127mm 275 lbs 125 kg 95 lbs 43 kg
0408605 PowerTwist Plus® Antistatic 25ft B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0408601 PowerTwist Plus® Antistatic 100ft B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
040860010 PowerTwist Plus® Antistatic 10m B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
0408600 PowerTwist Plus® Antistatic 30m B 5.5" 140mm 612 lbs 278 kg 204 lbs 93 kg
