L04OP80AR by Fenner Drives | Eagle 80 V Belting | Cross Section A/13 | 1/2" w x 5/16" h, 13mm w x 8mm h | Reinforced | Opaque | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| L04OP80AR | Eagle Opaque 80 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.15" | 80mm | 5.9 | 26.3 | 16 | 71.1 | 24 | 106.9 | 29.4 | 130.7 | 0.066 lbs | 0.099 kg |
| 4940066 | Eagle Orange 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.13" | 80mm | 3.9 | 17.3 | 9.3 | 41.2 | 14.8 | 65.8 | 19.5 | 86.6 | 0.065 lbs | 0.097 kg |
| L04I85AR | Eagle Ivory 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.15" | 80mm | 4.9 | 21.9 | 14.8 | 66 | 23.6 | 105.1 | 30.1 | 134.1 | 0.065 lbs | 0.096 kg |
| L04G89AR | Eagle Green 89 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.15" | 80mm | 3.8 | 16.8 | 14.3 | 63.5 | 53.9 | 239.9 | 88.7 | 394.8 | 0.065 lbs | 0.096 kg |
| 4940075 | Eagle Beige 95 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.78" | 96mm | 20.9 | 93 | 48.8 | 217.1 | 71.6 | 318.4 | 88.1 | 391.7 | 0.067 lbs | 0.099 kg |
| 4940071 | Eagle Beige 95 | A/13 Cogged | 1/2 x 5/16" | 13 x 8mm | 2.78" | 71mm | 20.9 | 93 | 48.8 | 217.1 | 71.6 | 318.4 | 88.1 | 391.7 | 0.067 lbs | 0.099 kg |
| 5260200 | Eagle Hyfen 95 | A | 1/2 x 3/8" | --- | 3.75" | 95mm | 18.3 | 81.3 | 26.6 | 118.2 | 34.1 | 151.8 | 41.3 | 183.6 | 0.077 lbs | 0.114 kg |
| 5220000 | Eagle Hyfen 95 | A Cogged | 1/2 x 3/8" | --- | 2.75" | 70mm | 18.3 | 81.3 | 26.6 | 118.2 | 34.1 | 151.8 | 41.3 | 183.6 | 0.077 lbs | 0.114 kg |
| 5299007 | Eagle Hyfen 85 | A Ridge-Top | 1/2 x 9/16" | --- | 6.19" | 157mm | 17.4 | 77.4 | 25.1 | 111.5 | 33.8 | 150.2 | 42.8 | 190.2 | 0.1 lbs | 0.148 kg |
| 5299019 | Eagle Hyfen 85 | A Twin | 1-3/16 x 5/16" | --- | 3.44" | 87mm | 45.5 | 202.2 | 34.4 | 153.2 | 44.9 | 199.9 | 54.9 | 244.2 | 0.151 lbs | 0.224 kg |
| 5260520 | Eagle Hyfen 85 CXF | A | 0.50 x 0.51" | --- | 4.53" | 115mm | 17.4 | 77.4 | 25.1 | 111.5 | 33.8 | 150.2 | 42.8 | 190.2 | 0.103 lbs | 0.153 kg |
| 5260520 | Eagle Hyfen 85 CXR | A | 1.19 x 0.41" | --- | 4.53" | 115mm | 17.4 | 77.4 | 25.1 | 111.5 | 33.8 | 150.2 | 42.8 | 190.2 | 0.088 lbs | 0.131 kg |
| 5260572 | Eagle Hyfen 85 CXF | A Twin | 0.50 x 0.51" | --- | 4.53" | 115mm | 45.5 | 202.2 | 34.4 | 153.2 | 44.9 | 199.9 | 54.9 | 244.2 | 0.203 lbs | 0.302 kg |
| 5260577 | Eagle Hyfen 85 CXR | A Twin | 1.19 x 0.41" | --- | 4.53" | 115mm | 45.5 | 202.2 | 34.4 | 153.2 | 44.9 | 199.9 | 54.9 | 244.2 | 0.174 lbs | 0.259 kg |
| 493060030M | Eagle Ivory 85 SGT PU | A/13 | 0.50 x 0.47" | 13 x 12.06mm | 4.11" | 104mm | 4.9 | 21.9 | 14.8 | 66 | 23.6 | 105.1 | 30.1 | 134.1 | 0.085 lbs | 0.127 kg |
| L04I85ARSG | Eagle Ivory 85 SGT PVC | A/13 | 0.50 x 0.53" | 13 x 13.51mm | 4.11" | 104mm | 4.9 | 21.9 | 14.8 | 66 | 23.6 | 105.1 | 30.1 | 134.1 | 0.095 lbs | 0.142 kg |
| 493150030M | Eagle Ivory 85 SGT TPE | A/13 | 0.50 x 0.48" | 13 x 12.34mm | 4.11" | 104mm | 4.9 | 21.9 | 14.8 | 66 | 23.6 | 105.1 | 30.1 | 134.1 | 0.084 lbs | 0.124 kg |
