L04BE95B by Fenner Drives | Eagle 95 V Belting | Cross Section B/17 | 21/32" w x 7/16" h, 17mm w x 11.5mm h | Non-Reinforced | Beige | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section |
Dimensions w x h* |
Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| 4941109 | Eagle Blue 80 MD | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 3.17" | 81mm | 5 | 22 | 8.4 | 37.3 | 11.8 | 52.6 | 15.1 | 67 | 0.113 lbs | 0.168 kg |
| 4940010 | Eagle Opaque 80 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 3.17" | 81mm | 7.4 | 33.1 | 15.3 | 68 | 24.1 | 107.2 | 32.5 | 144.5 | 0.121 lbs | 0.18 kg |
| 1032047 | Eagle Orange 85 | B/17 | 11/16 x 13/32" | 17.5 x 10mm | 3.25" | 83mm | 7 | 31.1 | 11.8 | 52.7 | 16.6 | 73.9 | 21.1 | 93.7 | 0.116 lbs | 0.172 kg |
| 4912069 | Eagle Clear 85 | B/17 | 11/16 x 13/32" | 17.5 x 10mm | 3.25" | 83mm | 7.2 | 31.9 | 12.1 | 54 | 17 | 75.8 | 21.6 | 96 | 0.116 lbs | 0.172 kg |
| L04I85B | Eagle Ivory 85 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 3.62" | 92mm | 20.6 | 91.6 | 31.4 | 139.8 | 41.2 | 183.4 | 49.9 | 222.2 | 0.118 lbs | 0.175 kg |
| L04BL85B | Eagle Blue 85 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 3.25" | 92mm | 7.3 | 31 | 12.4 | 52.5 | 17.4 | 73.7 | 22 | 93.4 | 0.121 lbs | 0.18 kg |
| L04G89B | Eagle Green 89 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 4.07" | 104mm | 37 | 164.4 | 56.4 | 251.1 | 73.9 | 328.7 | 89.1 | 396.4 | 0.112 lbs | 0.178 kg |
| 4911069 | Eagle Clear 95 | B/17 | 11/16 x 13/32" | 17.5 x 10mm | 4.13" | 105mm | 13.2 | 58.6 | 21.5 | 95.5 | 28.9 | 128.6 | 35.2 | 156.8 | 0.119 lbs | 0.177 kg |
| L04BY40B | Eagle White 40D | B/17 | 21/32 x 7/16" | 17 x 11mm | 5.2" | 132mm | 27.6 | 122.6 | 47.1 | 209.5 | 64.9 | 288.9 | 80.3 | 357 | 0.114 lbs | 0.17 kg |
| 4940030 | Eagle Red 90 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 4.5" | 115mm | 49.3 | 219.3 | 71 | 315.9 | 89.4 | 397.5 | 104.6 | 465.2 | 0.12 lbs | 0.178 kg |
| L04BE95B | Eagle Beige 95 | B/17 | 21/32 x 7/16" | 17 x 11.5mm | 4.5" | 115mm | 30.4 | 135.1 | 45.4 | 201.9 | 58.6 | 260.8 | 70.2 | 312.3 | 0.124 lbs | 0.184 kg |
| 1032046 | Eagle Orange 85 | B/17 Ribbed | 11/16 x 13/32" | 17.5 x 10mm | 3.25" | 83mm | 6.5 | 28.7 | 10.9 | 48.6 | 15.3 | 68.3 | 19.4 | 86.5 | 0.107 lbs | 0.159 kg |
| L04G89BX | Eagle Green 89 | B/17 Ridge-Top | --- | 17 x 19.5mm | 6.91" | 176mm | 53.7 | 238.9 | 82 | 364.9 | 107.4 | 477.7 | 129.5 | 576.1 | 0.174 lbs | 0.259 kg |
| 1032048 | Eagle Orange 85 | B/17 Wing-Top | 11/16 x 5/8" | --- | 5" | 127mm | 7.8 | 34.6 | 13.2 | 58.7 | 18.5 | 82.3 | 23.5 | 104.3 | 0.129 lbs | 0.192 kg |
| 1232600 | Eagle Orange 85 | BB | 11/16 x 9/16" | --- | 4.5" | 114mm | 10.3 | 45.8 | 17.5 | 77.7 | 24.5 | 109 | 31.1 | 138.1 | 0.171 lbs | 0.254 kg |
| 4911070 | Eagle Clear 95 | BB | 11/16 x 9/16" | --- | 5.63" | 143mm | 19.4 | 86.5 | 31.7 | 140.9 | 42.6 | 189.6 | 52 | 231.1 | 0.175 lbs | 0.26 kg |
| 4924330 | Eagle Red 85 CXF | B/17 | 0.69 x 0.5" | 17.5 x 12.54mm | 4.28" | 109mm | 8.1 | 36.1 | 12.8 | 57 | 17.4 | 77.5 | 21.7 | 96.7 | 0.15 lbs | 0.223 kg |
| 493040030M | Eagle Ivory 85 SGT PU | B/17 | 0.66 x 0.60" | 17 x 15.56mm | 4.28" | 109mm | 20.6 | 91.6 | 31.4 | 139.8 | 41.2 | 183.4 | 49.9 | 222.2 | 0.146 lbs | 0.218 kg |
| L04I85BSG | Eagle Ivory 85 SGT PVC | B/17 | 0.66 x 0.66" | 17 x 17.01mm | 4.28" | 109mm | 20.6 | 91.6 | 31.4 | 139.8 | 41.2 | 183.4 | 49.9 | 222.2 | 0.158 lbs | 0.235 kg |
| 493130030M | Eagle Ivory 85 SGT TPE | B/17 | 0.66 x 0.61" | 17 x 15.84mm | 4.28" | 109mm | 20.6 | 91.6 | 31.4 | 139.8 | 41.2 | 183.4 | 49.9 | 222.2 | 0.39 lbs | 0.215 kg |
| L04G89BSG | Eagle Green 89 SGT PVC | B/17 | 0.66 x 0.66" | 17 x 17.01mm | 4.82" | 122mm | 37 | 164.4 | 56.4 | 251.1 | 73.9 | 328.7 | 89.1 | 396.4 | 0.16 lbs | 0.238 kg |
| L04R90BSG | Eagle Red 90 SGT PVC | B/17 | 0.66 x 0.66" | 17 x 17.01mm | 4.82" | 122mm | 49.3 | 219.3 | 71 | 315.9 | 89.4 | 397.5 | 104.6 | 465.2 | 0.16 lbs | 0.238 kg |
| L04BY40BSG | Eagle White 40D SGT PVC | B/17 | 0.66 x 0.66" | 17 x 17.01mm | 6.96" | 177mm | 27.6 | 122.6 | 47.1 | 209.51 | 64.9 | 288.9 | 80.3 | 357 | 0.154 lbs | 0.229 kg |
* w (width) is the widest part of the belt. h (height) is the tallest part of the belt, including the belting top surface. Dimensions are for reference only.
