4928007 by Fenner Drives | Eagle 80 EC Round Belting | 3/8" x 9mm Diameter | Non-Reinforced | Blue | 100ft

4928007 by Fenner Drives | Eagle 80 EC Round Belting | 3/8" x 9mm Diameter | Non-Reinforced | Blue | 100ft

Sale price$363.68
Fenner Drives - Conveying - Round Belting - 9mm, 9.5mm, 3/8" Round Cross Sections - Non-Reinforced

Package Quantity: 100 FT

Buy More, Save More!
Quantity Price Each
5–14 $341.86
15–29 $309.13
30+ $272.76
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Eagle
Series:
  • 80 EC Series
Overview:
  • Eagle Blue 80 EC Non-Reinforced Round Belting is made of solid polyurethane designed specifically for direct food contact within the framework defined by the Regulation 1935/2004/EC. Also offers excellent abrasion resistance and high elasticity. Packaged in 100'/30.5m lengths.
Description:
  • Eagle Blue 80 EC Non-Reinforced Round Belting is Fenner Drives' latest addition to the already stellar Eagle line. This Eagle premium belt is suitable for repeat use direct food contact at temperatures up to 40 deg C (104 deg. F) with all food types having a pH of greater than 4.5.

    Best Suited For: Light duty conveying applications involving direct food contact.

    Independently certified to meet the requirements of European Regulation 10/2011 (and the legislation which it replaces; Commission Directive 2002/72/EC) within the framework defined by the Regulation 1935/2004/EC (27/10/2004) relating to plastic materials and articles intended to come into direct contact with foodstuffs.

    When used in a range of "typical" process environments, Eagle EC belting will not allow components to migrate into food in quantities that could endanger human health, change the composition of the food in an unacceptable way or deteriorate the taste and smell of foodstuffs.

  • 80 Shore A durometer polyurethane belting
  • Eagle premium belting for repeated direct food contact
  • Independently tested and verified to meet FDA standards for direct food contact
  • For repeat use food contact at temps up to 40 deg. C with all types having a pH greater than 4.5.
  • Solid polyurethane construction


    • Produced in accordance with Good Manufacturing Practice (GMP) standards with exacting quality control, Eagle EC Belting is of such dimensional consistency sanitary conveyor system performance and reliability is improved.

    Eagle Blue EC Non-Reinforced Round Belts are easily welded endless in the field with a Fenner Drives Butt Welding Kit.

SPECIFICATIONS

Profile Shape: Round Profile Size: 10mm, 8mm, 9.5mm
Reinforcement: None Color: Blue
Compliancy: EC Food Safety, FDA, REACH, RoHS Durometer: 80A
Material: Polyurethane Package Length: 100'/30.5m

Part Number Material & Color Dimensions Ø Minimum Pulley Ø Working Load @ Percent Tension Weight
4% 6% 8% 10%
in mm in mm lbs N lbs N lbs N lbs N lbs/ft kg/m
L04G899 Eagle Green 89 Textured --- 9mm 3.19" 81mm 4.7 21 7.7 34.4 10.6 47.2 13.3 59 0.051 lbs 0.076 kg
4941103 Eagle Blue 80 MD 3/8" 9.5mm 2.63" 67mm 3 13.5 4.7 20.9 6.3 27.9 7.8 34.8 0.054 lbs 0.08 kg
4940005 Eagle Opaque 80 3/8" 9.5mm 2.63" 67mm 4.7 20.8 8 35.4 11.1 49.4 14 62.3 0.058 lbs 0.087 kg
1032012 Eagle Orange 85 3/8" 9.5mm 3" 76mm 4.4 19.4 6.7 29.9 9 39.9 11.1 49.2 0.057lbs 0.086 kg
4908018 Eagle Clear 85 3/8" 9.5mm 3" 76mm 4.4 19.4 6.7 29.9 9 39.9 11.1 49.2 0.057lbs 0.086 kg
4940025 Eagle Red 90 3/8" 9.5mm 3.75" 95mm 23.9 106.1 34.4 152.9 43.3 192.4 50.6 225.1 0.058 lbs 0.086 kg
4907018 Eagle Clear 95 3/8" 9.5mm 3.75" 95mm 8.2 36.3 12.1 53.9 15.6 69.3 18.5 82.4 0.059 lbs 0.088 kg
4934018 Eagle Clear 85 QC .375 x .152"* --- 3" 76mm 1.8 8.2 2.9 12.7 3.8 17.1 4.7 21 0.048 lbs 0.071 kg
4934025 Eagle Yellow 85 QC .375 x .152"* --- 3" 76mm 1.8 8.2 2.9 12.7 3.8 17.1 4.7 21 0.048 lbs 0.071 kg
4928007 Eagle Clear 95 3/8" 9.5mm 2.62" 67mm 3.4 15 5.2 23.2 7 31 8.7 38.7 0.053 lbs 0.079 kg

* QC dimensions are shown O.D x I.D. (O.D. is the outer diameter of the belt. I.D. is the inner diameter of the belt.) Dimensions are for reference only.

Fenner Drives

Fenner Drives is a leading manufacturer of products for power transmission, motion transfer, and conveying applications. We consistently blend reliability, quality, and value across our entire product portfolio, which includes tensioners, pulleys and idlers, and bearings.
