L04BL85A by Fenner Drives | Eagle 85 V Belting | Cross Section A/13 | 1/2" w x 5/16" h, 13mm w x 8mm h | Non-Reinforced | Blue | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| 4928013 | Eagle Blue 80 EC | A/13 | --- | 13 x 8mm | 2.2" | 56mm | 3.4 | 14.9 | 6.1 | 27.3 | 8.6 | 38.2 | 11.1 | 49.3 | 0.062 lbs | 0.092 kg |
| 4927013 | Eagle Clear 80 EC | A/13 | --- | 13 x 8mm | 2.2" | 56mm | 3.4 | 14.9 | 6.1 | 27.3 | 8.6 | 38.2 | 11.1 | 49.3 | 0.062 lbs | 0.092 kg |
| 4941108 | Eagle Blue 80 MD | A/13 | 1/2" x 5/16" | 13 x 8mm | 2.2" | 56mm | 2.8 | 12.6 | 4.8 | 21.5 | 6.8 | 30.4 | 8.8 | 38.9 | 0.061 lbs | 0.091 kg |
| 4940009 | Eagle Opaque 80 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.2" | 56mm | 4.1 | 18.1 | 8.4 | 37.3 | 13.2 | 58.8 | 17.8 | 79.2 | 0.066 lbs | 0.099 kg |
| 1032038 | Eagle Orange 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.5" | 64mm | 4 | 17.6 | 6.7 | 29.9 | 9.4 | 41.9 | 11.9 | 53.1 | 0.066 lbs | 0.098 kg |
| 4912066 | Eagle Clear 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.5" | 64mm | 4.1 | 18.1 | 6.9 | 30.6 | 9.7 | 43 | 12.2 | 54.4 | 0.066 lbs | 0.098 kg |
| L04I85A | Eagle Ivory 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.52" | 64mm | 11.2 | 50 | 17.2 | 76.4 | 22.5 | 100.2 | 27.3 | 121.4 | 0.065 lbs | 0.096 kg |
| L04BL85A | Eagle Blue 85 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.5" | 64mm | 4 | 18 | 6.8 | 30.4 | 9.5 | 42.7 | 12 | 54.1 | 0.066 lbs | 0.098 kg |
| L04G89A | Eagle Green 89 | A/13 | 1/2 x 5/16" | 13 x 8mm | 2.83" | 72mm | 20.2 | 89.8 | 30.8 | 137.2 | 40.4 | 179.6 | 48.7 | 216.6 | 0.066 lbs | 0.098 kg |
| 4940029 | Eagle Red 90 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.13" | 80mm | 27 | 120.2 | 38.9 | 173.1 | 49 | 217.9 | 57.3 | 255 | 0.066 lbs | 0.098 kg |
| L04BE95A | Eagle Beige 95 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.1" | 80mm | 16.6 | 73.8 | 24.8 | 110.3 | 32 | 142.5 | 38.4 | 170.7 | 0.068 lbs | 0.101 kg |
| 4911066 | Eagle Clear 95 | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.13" | 79mm | 7.5 | 33.2 | 12.2 | 54.2 | 16.4 | 72.9 | 20 | 88.9 | 0.067 lbs | 0.1 kg |
| L04BY40A | Eagle White 40D | A/13 | 1/2 x 5/16" | 13 x 8mm | 3.78" | 96mm | 15.5 | 69.1 | 26.6 | 118.1 | 36.6 | 162.8 | 45.2 | 201.2 | 0.064 lbs | 0.096 kg |
| L04BY55A | Eagle Blue 55D | A/13 | 1/2 x 5/16" | 13 x 8mm | 4.09" | 104mm | 60.3 | 268.3 | 88.6 | 394.3 | 111.3 | 495 | 128.8 | 573.1 | 0.066 lbs | 0.098 kg |
| 4924320 | Eagle Red 85 CXF | A/13 | 0.50 x 0.41" | 13 x 10.54mm | 3.28" | 83mm | 4.6 | 20.5 | 7.3 | 32.3 | 9.9 | 44 | 12.3 | 54.8 | 0.091 lbs | 0.135 kg |
| 493030030M | Eagle Ivory 85 SGT PU | A/13 | 0.50 x 0.47" | 13 x 12.06mm | 3.28" | 83mm | 11.2 | 50 | 17.2 | 76.4 | 22.5 | 100.2 | 27.3 | 121.4 | 0.085 lbs | 0.127 kg |
| L04I85ASG | Eagle Ivory 85 SGT PVC | A/13 | 0.50 x 0.53" | 13 x 13.51mm | 3.28" | 83mm | 11.2 | 50 | 17.2 | 76.4 | 22.5 | 100.2 | 27.3 | 121.4 | 0.095 lbs | 0.142 kg |
| 493120030M | Eagle Ivory 85 SGT TPE | A/13 | 0.50 x 0.48" | 13 x 12.34mm | 3.28" | 83mm | 11.2 | 50 | 17.2 | 76.4 | 22.5 | 100.2 | 27.3 | 121.4 | 0.028 lbs | 0.124 kg |
| L04G89ASG | Eagle Green 89 SGT PVC | A/13 | 0.50 x 0.53" | 13 x 13.51mm | 3.69" | 94mm | 20.2 | 89.8 | 30.8 | 137.2 | 40.4 | 179.6 | 48.7 | 216.6 | 0.096 lbs | 0.143 kg |
| L04R90ASG | Eagle Red 90 SGT PVC | A/13 | 0.50 x 0.53" | 13 x 13.51mm | 3.69" | 94mm | 27 | 120.2 | 38.9 | 173.1 | 49 | 217.9 | 57.3 | 255 | 0.096 lbs | 0.143 kg |
| L04BY40ASG | Eagle White 40D SGT PVC | A/13 | 0.50 x 0.53" | 13 x 13.51mm | 5.34" | 136mm | 15.5 | 69.1 | 26.6 | 118.1 | 36.6 | 162.8 | 45.2 | 201.2 | 0.095 lbs | 0.141 kg |
| 1032040 | Eagle Orange 85 | A/13 Hi-Ridge-Top | 1/2 x 5/8" | --- | 5" | 127mm | 5.5 | 24.7 | 9.4 | 41.8 | 13.2 | 58.7 | 16.7 | 74.3 | 0.92 lbs | 0.137 kg |
| 4911102 | Eagle Clear 85 | A/13 Hi-Ridge-Top | 1/2 x 5/8" | --- | 5" | 127mm | 5.3 | 23.7 | 9 | 40.1 | 12.7 | 56.3 | 16 | 71.3 | 0.086 lbs | 0.128 kg |
| 1032039 | Eagle Orange 85 | A/13 Lo-Ridge-Top | 1/2 x 7/16" | --- | 3.5" | 89mm | 4.3 | 19.1 | 7.3 | 32.4 | 10.2 | 45.4 | 12.9 | 57.5 | 0.071 lbs | 0.106 kg |
| 4912067 | Eagle Clear 85 | A/13 Lo-Ridge-Top | 1/2 x 7/16" | --- | 3.5" | 89mm | 4.3 | 19.3 | 7.3 | 32.6 | 10.3 | 45.8 | 13 | 58 | 0.07 lbs | 0.104 kg |
| L04G89AX | Eagle Green 89 | A/13 Ridge-Top | --- | 13 x 16mm | 5.67" | 144mm | 33 | 146.8 | 50.4 | 224.3 | 66 | 293.6 | 79.6 | 354.1 | 0.107 lbs | 0.159 kg |
| 1032041 | Eagle Orange 85 | A Twin | 1-3/16 x 5/16" | --- | 2.5" | 64mm | 9.3 | 41.4 | 15.8 | 70.2 | 22.1 | 98.5 | 28.1 | 124.8 | 0.154 lbs | 0.23 kg |
| 4912068 | Eagle Clear 85 | A Twin | 1-3/16 x 5/16" | --- | 2.5" | 64mm | 9.6 | 42.5 | 16.2 | 72 | 22.7 | 100.9 | 28.7 | 127.9 | 0.154 lbs | 0.23 kg |
| 1232550 | Eagle Orange 85 | AA | 1/2 x 13/32" | --- | 3.25" | 83mm | 5.6 | 25.1 | 9.6 | 42.5 | 13.4 | 59.6 | 17 | 75.5 | 0.093 lbs | 0.139 kg |
