L04BE958 by Fenner Drives | Eagle 95 Round Belting | 8mm Diameter | Non-Reinforced | Beige | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | ||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | ||
| L04OG857M | Eagle Orange 85 | --- | 7mm | 2.2" | 56mm | 2.4 | 10.5 | 3.6 | 16.2 | 4.8 | 21.6 | 6 | 26.6 | 0.031 lbs | 0.046 kg |
| L04C857M | Eagle Clear 85 | --- | 7mm | 2.2" | 56mm | 2.4 | 10.5 | 3.6 | 16.2 | 4.8 | 21.6 | 6 | 26.6 | 0.031 lbs | 0.046 kg |
| 4999637 | Eagle Green 89 | --- | 7mm | 2.48" | 63mm | 3.9 | 17.4 | 6.4 | 28.6 | 8.8 | 39.3 | 11 | 49.1 | 0.031 lbs | 0.046 kg |
| 4905307 | Eagle Green 89 Textured | --- | 7mm | 2.48" | 63mm | 2.9 | 12.7 | 4.7 | 20.9 | 6.4 | 28.7 | 8.1 | 35.8 | 0.031 lbs | 0.046 kg |
| L04R907 | Eagle Red 90 | --- | 7mm | 2.76" | 70mm | 12.9 | 57.4 | 18.6 | 82.7 | 23.4 | 104.1 | 27.4 | 121.8 | 0.031 lbs | 0.047 kg |
| 4941102 | Eagle Blue 80 MD | 5/16" | --- | 2.19" | 56mm | 2.1 | 9.4 | 3.3 | 14.5 | 4.3 | 19.3 | 5.5 | 24.3 | 0.037 lbs | 0.055 kg |
| 1032010 | Eagle Orange 85 | 5/16" | --- | 2.5" | 64mm | 3 | 13.5 | 4.7 | 20.8 | 6.2 | 27.7 | 7.7 | 34.1 | 0.04 lbs | 0.059 kg |
| 4908015 | Eagle Clear 85 | 5/16" | --- | 2.5" | 64mm | 3 | 13.5 | 4.7 | 20.8 | 6.2 | 27.7 | 7.7 | 34.1 | 0.04 lbs | 0.059 kg |
| 4934015 | Eagle Clear 85 QC | .313" x .126*" | --- | 2.5" | 64mm | 1.3 | 5.7 | 2 | 8.9 | 2.7 | 11.9 | 3.3 | 14.7 | 0.034 lbs | 0.05 kg |
| 4934023 | Eagle Yellow 85 QC | .313" x .126*" | --- | 2.5" | 64mm | 1.3 | 5.7 | 2 | 8.9 | 2.7 | 11.9 | 3.3 | 14.7 | 0.034 lbs | 0.05 kg |
| 4928006 | Eagle Blue 80 EC | --- | 8mm | 2.2" | 56mm | 2.4 | 10.5 | 3.6 | 16.2 | 4.8 | 21.5 | 6.1 | 26.9 | 0.038 lbs | 0.056 kg |
| 4927006 | Eagle Clear 80 EC | --- | 8mm | 2.2" | 56mm | 2.4 | 10.5 | 3.6 | 16.2 | 4.8 | 21.5 | 6.1 | 26.9 | 0.038 lbs | 0.056 kg |
| L04OP808M | Eagle Opaque 80 | --- | 8mm | 2.2" | 56mm | 3.3 | 14.7 | 5.6 | 25 | 7.8 | 34.9 | 9.9 | 43.9 | 0.041 lbs | 0.061 kg |
| L04OG858M | Eagle Orange 85 | --- | 8mm | 2.52" | 64mm | 3.1 | 13.7 | 4.7 | 21.1 | 6.3 | 28.1 | 7.8 | 34.7 | 0.041 lbs | 0.06 kg |
| L04C858 | Eagle Clear 85 | --- | 8mm | 2.52" | 64mm | 3.1 | 13.7 | 4.7 | 21.1 | 6.3 | 28.1 | 7.8 | 34.7 | 0.041 lbs | 0.06 kg |
| L04BL858M | Eagle Blue 85 | --- | 8mm | 2.52" | 64mm | 3.1 | 13.7 | 4.7 | 21.1 | 6.3 | 28.1 | 7.8 | 34.7 | 0.041 lbs | 0.06 kg |
| L04G898MS | Eagle Green 89 | --- | 8mm | 2.83" | 72mm | 5.1 | 22.8 | 8.4 | 37.4 | 11.5 | 51.3 | 14.4 | 64.1 | 0.04 lbs | 0.06 kg |
| 4905308 | Eagle Green 89 Textured | --- | 8mm | 2.83" | 72mm | 3.7 | 16.6 | 6.1 | 27.2 | 8.4 | 37.3 | 10.5 | 46.7 | 0.04 lbs | 0.06 kg |
| 4940024 | Eagle Red 90 | --- | 8mm | 3.15" | 80mm | 16.8 | 74.9 | 24.3 | 107.9 | 30.5 | 135.8 | 35.7 | 158.9 | 0.041 lbs | 0.061 kg |
| L04BE958 | Eagle Beige 95 | --- | 8mm | 3.15" | 80mm | 13.6 | 60.5 | 19.3 | 85.7 | 24.1 | 107 | 28.1 | 125.1 | 0.042 lbs | 0.062 kg |
| L04QC858M | Eagle Clear 85 QC | --- | 8 x 3.2mm* | 2.52" | 64mm | 1.3 | 5.8 | 2 | 9 | 2.7 | 12.1 | 3.4 | 14.9 | 0.034 lbs | 0.051 kg |
| L04QR858M | Eagle Red 85 QC | --- | 8 x 3.2mm* | 2.52" | 64mm | 1.3 | 5.8 | 2 | 9 | 2.7 | 12.1 | 3.4 | 14.9 | 0.034 lbs | 0.051 kg |
| L04QB858M | Eagle Blue 85 QC | --- | 8 x 3.2mm* | 2.52" | 64mm | 1.3 | 5.7 | 2 | 8.9 | 2.7 | 11.9 | 3.3 | 14.6 | 0.034 lbs | 0.051 kg |
| L04CON8S | QC Connectors | 25/pack | |||||||||||||
* QC dimensions are shown O.D x I.D. (O.D. is the outer diameter of the belt. I.D. is the inner diameter of the belt.) Dimensions are for reference only.
