L04BL854 by Fenner Drives | Eagle 85 Round Belting | 4mm Diameter | Non-Reinforced | Blue | 100ft

L04BL854 by Fenner Drives | Eagle 85 Round Belting | 4mm Diameter | Non-Reinforced | Blue | 100ft

Minimum Order Quantity: 3 Units

Sale price$119.58
Fenner Drives - Conveying - Round Belting - 4mm, 5mm, 3/16" Round Cross Sections - Non-Reinforced
This is a Made-to-Order product and thus may have an extended lead time.

Package Quantity: 100 FT

Quantity Price Each
15–29 $113.60
30–59 $107.62
60+ $95.66
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Eagle
Series:
  • 85 Series
Overview:
  • N/A
Description:
  • N/A

SPECIFICATIONS

Profile Shape: N/A Profile Size: N/A
Reinforcement: N/A Color: N/A
Compliancy: N/A Durometer: N/A
Material: N/A Special Feature: N/A
Package Length: N/A

Part Number Material & Color Dimensions Ø Minimum Pulley Ø Working Load @ Percent Tension Weight
4% 6% 8% 10%
in mm in mm lbs N lbs N lbs N lbs N lbs/ft kg/m
4928002 Eagle Blue 80 EC --- 4mm 1.1" 28mm 0.6 2.8 0.9 4.2 1.3 5.6 1.5 6.7 0.009 lbs 0.014 kg
4927002 Eagle Clear 80 EC --- 4mm 1.1" 28mm 0.6 2.8 0.9 4.2 1.3 5.6 1.5 6.7 0.009 lbs 0.014 kg
L04OP804 Eagle Opaque 80 --- 4mm 1.1" 28mm 0.8 3.7 1.4 6.2 2 8.7 2.5 11 0.01 lbs 0.015 kg
L04OG854 Eagle Orange 85 --- 4mm 1.26" 32mm 0.8 3.4 1.2 5.3 1.6 7 1.9 8.6 0.01 lbs 0.015 kg
L04C854 Eagle Clear 85 --- 4mm 1.26" 32mm 0.8 3.4 1.2 5.3 1.6 7 1.9 8.6 0.01 lbs 0.015 kg
L04R8504 Eagle Red 85 --- 4mm 1.26" 32mm 0.8 3.4 1.2 5.3 1.6 7 2 8.7 0.01 lbs 0.015 kg
L04BL854 Eagle Blue 85 --- 4mm 1.26" 32mm 0.8 3.4 1.2 5.3 1.6 7 2 8.7 0.01 lbs 0.015 kg
4905404 Eagle Green 89 --- 4mm 1.42" 36mm 1.3 5.7 2.1 9.3 2.9 12.8 3.6 16 0.01 lbs 0.015 kg
4905304 Eagle Green 89 Textured --- 4mm 1.42" 36mm 0.9 4.1 1.5 6.8 2.1 9.3 2.6 11.6 0.01 lbs 0.015 kg
4940021 Eagle Red 90 --- 4mm 1.57" 40mm 4.2 18.6 6 26.8 7.6 33.8 8.9 39.5 0.01 lbs 0.015 kg
4941100 Eagle Blue 80 MD 3/16" --- 1.31" 33mm 0.8 3.5 1.2 5.4 1.6 7 1.9 8.6 0.013 lbs 0.02 kg
1032006 Eagle Orange 85 3/16" --- 1.5" 38mm 1.1 4.9 1.7 7.5 2.2 10 2.8 12.3 0.014 lbs 0.021 kg
4908009 Eagle Clear 85 3/16" --- 1.5" 38mm 1.1 4.9 1.7 7.5 2.2 10 2.8 12.3 0.014 lbs 0.021 kg
4940022 Eagle Red 90 3/16" --- 1.88" 48mm 6 26.5 8.6 38.2 10.8 48.1 12.6 56.2 0.014 lbs 0.022 kg
4907009 Eagle Clear 95 3/16" --- 1.88" 48mm 2 9.1 3 13.5 3.9 17.3 4.6 20.6 0.015 lbs 0.022 kg
4934009 Eagle Clear 85 QC .188" x .080" --- 1.5" 38mm 0.5 2 0.7 3.1 0.9 4.2 1.2 5.2 0.012 lbs 0.018 kg
4934021 Eagle Yellow 85 QC .188" x .080"* --- 1.5" 38mm 0.5 2 0.7 3.1 0.9 4.2 1.2 5.2 0.012 lbs 0.018 kg
4928003 Eagle Blue 80 EC --- 5mm 1.38" 35mm 0.9 4.2 1.4 6.3 1.9 8.4 2.4 10.6 0.015 lbs 0.022 kg
4927003 Eagle Clear 80 EC --- 5mm 1.38" 35mm 0.9 4.2 1.4 6.3 1.9 8.4 2.4 10.6 0.015 lbs 0.022 kg
L04OP805M Eagle Opaque 80 --- 5mm 1.38" 35mm 1.3 5.7 2.2 9.7 3.1 13.6 3.9 17.2 0.016 lbs 0.024 kg
4940100 Eagle Orange 85 --- 5mm 1.57" 40mm 1.2 5.4 1.9 8.3 2.5 11 3.1 13.6 0.016 lbs 0.024 kg
L04C855M Eagle Clear 85 --- 5mm 1.57" 40mm 1.2 5.3 1.9 8.3 2.5 11 3 13.5 0.016 lbs 0.024 kg
L04R855 Eagle Red 85 --- 5mm 1.57" 40mm 1.2 5.3 1.9 8.3 2.5 11 3 13.5 0.016 lbs 0.024 kg
L04BL855M Eagle Blue 85 --- 5mm 1.57" 40mm 1.2 5.3 1.9 8.3 2.5 11 3 13.5 0.016 lbs 0.024 kg
4905405 Eagle Green 89 --- 5mm 1.77" 45mm 2 8.9 3.3 14.6 4.5 20.1 5.6 25.1 0.016 lbs 0.023 kg
4905305 Eagle Green 89 Textured --- 5mm 1.77" 45mm 1.5 6.5 2.4 10.6 3.3 14.6 4.1 18.2 0.016 lbs 0.023 kg
L04R9005M Eagle Red 90 --- 5mm 1.97" 50mm 6 26.5 8.6 38.2 10.8 48.1 12.6 56.2 0.014 lbs 0.022 kg
L04BE955M Eagle Beige 95 --- 5mm 1.97" 50mm 5.3 23.6 7.5 33.4 9.4 41.8 11 48.8 0.016 lbs 0.024 kg
L04QC855M Eagle Clear 85 QC --- 5mm x 2mm* 1.57" 40mm 0.5 2.3 0.8 3.5 1.1 4.7 1.3 5.8 0.013 lbs 0.02 kg
L04QR855M Eagle Red 85 QC --- 5mm x 2mm* 1.57" 40mm 0.5 2.3 0.8 3.5 1.1 4.7 1.3 5.8 0.013 lbs 0.02 kg
4935009 QC Connectors 25/pack N/A N/A

Fenner Drives

Fenner Drives is a leading manufacturer of products for power transmission, motion transfer, and conveying applications. We consistently blend reliability, quality, and value across our entire product portfolio, which includes tensioners, pulleys and idlers, and bearings.
