L04BL850604 by Fenner Drives | Eagle 85 V Belt | Cross Section | 6.5mm w x 4mm h | Non-Reinforced | Blue | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | None | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| 4928009 | Eagle Blue 80 EC | 6mm x 4mm | --- | 6.5 x 4mm | 1.1" | 28mm | 0.8 | 3.7 | 1.5 | 6.7 | 2.1 | 9.4 | 2.7 | 12.1 | 0.015 lbs | 0.023 kg |
| 4927009 | Eagle Clear 80 EC | 6mm x 4mm | --- | 6.5 x 4mm | 1.1" | 28mm | 0.8 | 3.7 | 1.5 | 6.7 | 2.1 | 9.4 | 2.7 | 12.1 | 0.015 lbs | 0.023 kg |
| L04C850604 | Eagle Clear 85 | 6mm x 4mm | --- | 6.5 x 4mm | 1.26" | 32mm | 1 | 4.5 | 1.7 | 7.6 | 2.4 | 10.7 | 3 | 13.5 | 0.016 lbs | 0.024 kg |
| L04BL850604 | Eagle Blue 85 | 6mm x 4mm | --- | 6.5 x 4mm | 1.26" | 32mm | 1 | 4.5 | 1.7 | 7.6 | 2.4 | 10.7 | 3 | 13.5 | 0.016 lbs | 0.024 kg |
| 4928010 | Eagle Blue 80 EC | 8mm x 5mm | --- | 8 x 5mm | 1.38" | 35mm | 1.3 | 5.7 | 2.4 | 10.5 | 3.3 | 14.6 | 4.2 | 18.9 | 0.024 lbs | 0.035 kg |
| 4927010 | Eagle Clear 80 EC | 8mm x 5mm | --- | 8 x 5mm | 1.38" | 35mm | 1.3 | 5.7 | 2.4 | 10.5 | 3.3 | 14.6 | 4.2 | 18.9 | 0.024 lbs | 0.035 kg |
| 4940006 | Eagle Opaque 80 | 8mm x 5mm | --- | 8 x 5mm | 1.38" | 35mm | 1.6 | 7.1 | 3.3 | 14.7 | 5.2 | 23.1 | 7 | 31.2 | 0.015 lbs | 0.039 kg |
| L04BL8585M | Eagle Blue 85 | 8mm x 5mm | --- | 8 x 5mm | 1.57" | 40mm | 1.5 | 6.8 | 2.6 | 11.5 | 3.6 | 16.2 | 4.6 | 20.5 | 0.025 lbs | 0.038 kg |
| 4940027 | Eagle Red 90 | 8mm x 5mm | --- | 8 x 5mm | 2" | 50mm | 10.8 | 48.1 | 15.6 | 69.3 | 19.6 | 87.2 | 22.9 | 102 | 0.026 lbs | 0.039 kg |
* w (width) is the widest part of the belt.
h (height) is the tallest part of the belt, including the belting top surface.
Dimensions are for reference only.
