493170030M by Fenner Drives | Eagle 85 SGT TPE V Belting | Cross Section C/22 | 0.88" w x 0.73" h | Reinforced | Ivory | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section |
Dimensions w x h* |
Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| 5260400 | Eagle Hyfen 95 | C | 7/8 x 5/8" | --- | 6.25" | 159mm | 39.8 | 177.2 | 57.9 | 257.6 | 74.4 | 330.8 | 90 | 400.3 | 0.226 lbs | 0.337 kg |
| 5240000 | Eagle Hyfen 95 | C Cogged | 7/8 x 5/8" | --- | 5.25" | 133mm | 39.8 | 177.2 | 57.9 | 257.6 | 74.4 | 330.8 | 90 | 400.3 | 0.226 lbs | 0.337 kg |
| 4940068 | Eagle Orange 85 | C/22 | 7/8 x 9/16" | 22 x 14.5mm | 5.62" | 145mm | 11.7 | 52 | 27.8 | 123.7 | 44.4 | 197.4 | 58.4 | 260 | 0.196 lbs | 0.291 kg |
| L04I85CR | Eagle Ivory 85 | C/22 | 7/8 x 9/16" | 22 x 14.5mm | 5.71" | 145mm | 14.8 | 65.7 | 44.6 | 198.3 | 71 | 315.7 | 90.5 | 402.7 | 0.194 lbs | 0.289 kg |
| L04G89CR | Eagle Green 89 | C/22 | --- | 22 x 14.5mm | 5.71" | 145mm | 11.5 | 51.3 | 43.6 | 193.9 | 164.6 | 732.4 | 270.9 | 1205.1 | 0.197 lbs | 0.293 kg |
| 4940077 | Eagle Beige 95 | C/22 | 7/8 x 9/16" | 22 x 14.5mm | 6.85" | 174mm | 63.8 | 284 | 149 | 662.7 | 218.5 | 971.9 | 268.8 | 1195.9 | 0.204 lbs | 0.303 kg |
| 4940073 | Eagle Beige 95 | C/22 Cogged | 7/8 x 9/16" | 22 x 14.5mm | 5.85" | 149mm | 63.8 | 284 | 149 | 662.7 | 218.5 | 971.9 | 268.8 | 1195.9 | 0.204 lbs | 0.303 kg |
| 5299103 | Eagle Ivory 85 | C/22 Ridge-Top | --- | 22 x 24.5 | 9.65 | 245mm | 21.7 | 96.6 | 65.6 | 291.7 | 104.4 | 464.3 | 133.2 | 592.4 | 0.285 lbs | 0.424 kg |
| L04I85CRXH | Eagle Ivory 85 | C/22 Ridge-Top | --- | 22 x 28.5mm | 11.22" | 285mm | 24.4 | 108.5 | 73.7 | 327.7 | 117.3 | 521.6 | 149.6 | 665.4 | 0.32 lbs | 0.477 kg |
| 4999524 | Eagle Green 89 | C/22 Ridge-Top | --- | 22 x 24.5mm | 9.65" | 245mm | 16.2 | 72.3 | 61.4 | 273.1 | 231.8 | 1031.3 | 381.5 | 1697 | 0.278 lbs | 0.413 kg |
| L04G89CRXH | Eagle Green 89 | C/22 Ridge-Top | --- | 22 x 24.5mm | 9.65" | 245mm | 16.2 | 72.3 | 61.4 | 273.1 | 231.8 | 1031.3 | 381.5 | 1697 | 0.278 lbs | 0.413 kg |
| 5260540 | Eagle Green 89 | C/22 Ridge-Top | --- | 22 x 28.5mm | 11.22" | 285mm | 18.7 | 83.4 | 70.8 | 315.1 | 267.5 | 1189.8 | 440.1 | 1957.8 | 0.32 lbs | 0.477 kg |
| 5260545 | Eagle Hyfen 85 CXR | C | 0.88 x 0.63" | --- | 7.7" | 196mm | 38 | 169.1 | 54.7 | 243.4 | 73.7 | 327.9 | 93.4 | 415.4 | 0.215 lbs | 0.32 kg |
| 493070030M | Eagle Ivory 85 SGT PU | C/22 | 0.88 x 0.72" | 22 x 18.56mm | 6.61" | 168mm | 14.8 | 65.8 | 44.6 | 198.3 | 71 | 315.7 | 90.5 | 402.7 | 0.227 lbs | 0.338 kg |
| L04I85CRSG | Eagle Ivory 85 SGT PVC | C/22 | 0.88 x 0.78" | 22 x 20.01mm | 6.61" | 168mm | 14.8 | 65.8 | 44.6 | 198.3 | 71 | 315.7 | 90.5 | 402.7 | 0.245 lbs | 0.365 kg |
| 493170030M | Eagle Ivory 85 SGT TPE | C/22 | 0.88 x 0.73" | 22 x 18.84mm | 6.61" | 168mm | 14.8 | 65.8 | 44.6 | 198.3 | 71 | 315.7 | 90.5 | 402.7 | 0.224 lbs | 0.334 kg |
* w (width) is the widest part of the belt. h (height) is the tallest part of the belt, including the belting top surface. Dimensions are for reference only.
