4911063 by Fenner Drives | Eagle 95 V Belt | Cross Section: 3L | 3/8" w x 7/32" h | Non-Reinforced | Clear | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | N/A | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Package Length: | N/A |
| Part Number | Material & Color | Cross Section | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | |||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | |||
| 1032030 | Eagle Orange 85 | 3L | 3/8" x 7/32" | --- | 1.75" | 44mm | 2.1 | 9.5 | 3.6 | 16.1 | 5.1 | 22.6 | 6.4 | 28.6 | 0.035 lbs | 0.053 kg |
| 4912063 | Eagle Clear 85 | 3L | 3/8" x 7/32" | --- | 1.75" | 44mm | 2.2 | 9.7 | 3.7 | 16.5 | 5.2 | 23.1 | 6.6 | 29.3 | 0.035 lbs | 0.053 kg |
| L04BL853L | Eagle Blue 85 | 3L | 3/8" x 7/32" | --- | 1.75" | 45mm | 2.1 | 9.5 | 3.6 | 16.1 | 5.1 | 22.6 | 6.4 | 28.6 | 0.035 lbs | 0.053 kg |
| 4911063 | Eagle Clear 95 | 3L | 3/8" x 7/32" | --- | 2.19" | 56mm | 4 | 17.9 | 6.6 | 29.2 | 8.8 | 39.3 | 10.8 | 47.9 | 0.036 lbs | 0.054 kg |
| 1032032 | Eagle Orange 85 | 3L Crown-Top | 9/16" x 1/4" | --- | 2" | 51mm | 3 | 13.2 | 5 | 22.4 | 7.1 | 31.5 | 9 | 39.9 | 0.049 lbs | 0.073 kg |
| 1032031 | Eagle Orange 85 | 3L T-Top | 9/16" x 19/64" | --- | 2.38" | 60mm | 3.5 | 15.7 | 6 | 26.5 | 8.4 | 37.2 | 10.6 | 47.2 | 0.058 lbs | 0.087 kg |
| 4912064 | Eagle Clear 85 | 3L T-Top | 9/16" x 19/64" | --- | 2.38" | 60mm | 3.6 | 16.1 | 6.1 | 27.2 | 8.6 | 38.2 | 10.9 | 48.3 | 0.058 lbs | 0.087 kg |
| 1032033 | Eagle Orange 85 | 3L Twin | 15/16" x 17/64" | --- | 2.13" | 54mm | 5.9 | 26.2 | 10 | 44.5 | 14 | 62.4 | 17.8 | 79 | 0.098 lbs | 0.145 kg |
| 4912065 | Eagle Clear 85 | 3L Twin | 15/16" x 17/64" | --- | 2.13" | 54mm | 6 | 26.9 | 10.2 | 45.6 | 14.4 | 63.9 | 18.2 | 81 | 0.098 lbs | 0.145 kg |
| 4911065 | Eagle Clear 95 | 3L Twin | 15/16" x 17/64" | --- | 2.5" | 64mm | 11.1 | 49.5 | 18.1 | 80.6 | 24.4 | 108.5 | 29.7 | 132.2 | 0.1 lbs | 0.149 kg |
| 4940008 | Eagle Opaque 80 | Z/10 | --- | 10 x 6.5mm | 1.79" | 46mm | 2.5 | 11.3 | 5.2 | 23.3 | 8.3 | 36.8 | 11.1 | 49.5 | 0.041 lbs | 0.062 kg |
| 4940114 | Eagle Orange 85 | Z/10 | --- | 10 x 6.5mm | 1.88" | 52mm | 2.5 | 10.9 | 4.2 | 18.5 | 5.8 | 26 | 7.4 | 32.9 | 0.041 lbs | 0.061 kg |
| 4940118 | Eagle Clear 85 | Z/10 | --- | 10 x 6.5mm | 2.05" | 52mm | 2.5 | 11.2 | 4.3 | 19 | 6 | 26.6 | 7.6 | 33.7 | 0.041 lbs | 0.061 kg |
| 4940118 | Eagle Ivory 85 | Z/10 | --- | 10 x 6.5mm | 2.05" | 52mm | 6.9 | 30.8 | 10.6 | 47 | 13.9 | 61.7 | 16.8 | 74.8 | 0.04 lbs | 0.06 kg |
| L04BL85Z | Eagle Blue 85 | Z/10 | --- | 10 x 6.5mm | 1.88" | 52mm | 2.5 | 10.8 | 4.2 | 18.3 | 5.8 | 25.6 | 7.4 | 32.5 | 0.041 lbs | 0.061 kg |
| L04G89Z | Eagle Green 89 | Z/10 | --- | 10 x 6.5mm | 2.3" | 59mm | 12.4 | 55.3 | 19 | 84.5 | 24.9 | 110.6 | 30 | 133.4 | 0.04 lbs | 0.06 kg |
| 4940028 | Eagle Clear 85 | Z/10 | --- | 10 x 6.5mm | 2.5" | 65mm | 16.9 | 75.2 | 24.3 | 108.3 | 30.6 | 136.3 | 35.9 | 159.5 | 0.041 lbs | 0.061 kg |
