4905308 by Fenner Drives | Eagle 89 Textured Round Belting | 8mm Diameter | Non-Reinforced | Green | 100ft

4905308 by Fenner Drives | Eagle 89 Textured Round Belting | 8mm Diameter | Non-Reinforced | Green | 100ft

Sale price$385.05
Fenner Drives - Conveying - Round Belting - 7mm, 8mm, 5/16" Round Cross Sections - Non-Reinforced

Package Quantity: 100 FT

Buy More, Save More!
Quantity Price Each
5–14 $361.95
15–29 $327.29
30+ $288.79
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Eagle
Series:
  • 89 Series
Overview:
  • Eagle Green 89 Non-Reinforced Textured Round Belting constructed of polyurethane with an 89 Shore A durometer that provides excellent abrasion resistance. A key feature of this belt is its textured surface, which lowers its surface coefficient of friction. Packaged in 100'/30.5m lengths.
Description:
  • Eagle Green 89 Non-Reinforced Textured Round Belts' harder durometer and textured surface combine to lower the CoF of this belt. Eagle Green 89 Non-Reinforced Textured Round belts also have superior heat and water resistant properties making it an ideal choice for an application that requires frequent wash-downs.

    Best Suited For: Long conveyor lengths, heavier conveyed loads, or medium-duty power transmission applications, where a lower surface CoF (coefficient of friction) is desirable in a round belt profile.

  • 89 shore A durometer
  • Textured surface for lower surface CoF
  • Superior heat and water resistance
  • No take-ups required
  • REACH and RoHS 2002/95/EC Directive compliant


    • Eagle Green 89 Non-Reinforced Textured Round Belts are easily welded endless in the field with either a Fenner Drives Butt Welding Kit.


SPECIFICATIONS

Profile Shape: Round Profile Size: 10mm, 12mm, 15mm, 2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm
Reinforcement: None Color: Green
Compliancy: REACH, RoHS Durometer: 89A
Material: Polyurethane Special Feature: Textured Package Length: 100'/30.5m

Part Number Material & Color Dimensions Ø Minimum Pulley Ø Working Load @ Percent Tension Weight
4% 6% 8% 10%
in mm in mm lbs N lbs N lbs N lbs N lbs/ft kg/m
L04OG857M Eagle Orange 85 --- 7mm 2.2" 56mm 2.4 10.5 3.6 16.2 4.8 21.6 6 26.6 0.031 lbs 0.046 kg
L04C857M Eagle Clear 85 --- 7mm 2.2" 56mm 2.4 10.5 3.6 16.2 4.8 21.6 6 26.6 0.031 lbs 0.046 kg
4999637 Eagle Green 89 --- 7mm 2.48" 63mm 3.9 17.4 6.4 28.6 8.8 39.3 11 49.1 0.031 lbs 0.046 kg
4905307 Eagle Green 89 Textured --- 7mm 2.48" 63mm 2.9 12.7 4.7 20.9 6.4 28.7 8.1 35.8 0.031 lbs 0.046 kg
L04R907 Eagle Red 90 --- 7mm 2.76" 70mm 12.9 57.4 18.6 82.7 23.4 104.1 27.4 121.8 0.031 lbs 0.047 kg
4941102 Eagle Blue 80 MD 5/16" --- 2.19" 56mm 2.1 9.4 3.3 14.5 4.3 19.3 5.5 24.3 0.037 lbs 0.055 kg
1032010 Eagle Orange 85 5/16" --- 2.5" 64mm 3 13.5 4.7 20.8 6.2 27.7 7.7 34.1 0.04 lbs 0.059 kg
4908015 Eagle Clear 85 5/16" --- 2.5" 64mm 3 13.5 4.7 20.8 6.2 27.7 7.7 34.1 0.04 lbs 0.059 kg
4934015 Eagle Clear 85 QC .313" x .126*" --- 2.5" 64mm 1.3 5.7 2 8.9 2.7 11.9 3.3 14.7 0.034 lbs 0.05 kg
4934023 Eagle Yellow 85 QC .313" x .126*" --- 2.5" 64mm 1.3 5.7 2 8.9 2.7 11.9 3.3 14.7 0.034 lbs 0.05 kg
4928006 Eagle Blue 80 EC --- 8mm 2.2" 56mm 2.4 10.5 3.6 16.2 4.8 21.5 6.1 26.9 0.038 lbs 0.056 kg
4927006 Eagle Clear 80 EC --- 8mm 2.2" 56mm 2.4 10.5 3.6 16.2 4.8 21.5 6.1 26.9 0.038 lbs 0.056 kg
L04OP808M Eagle Opaque 80 --- 8mm 2.2" 56mm 3.3 14.7 5.6 25 7.8 34.9 9.9 43.9 0.041 lbs 0.061 kg
L04OG858M Eagle Orange 85 --- 8mm 2.52" 64mm 3.1 13.7 4.7 21.1 6.3 28.1 7.8 34.7 0.041 lbs 0.06 kg
L04C858 Eagle Clear 85 --- 8mm 2.52" 64mm 3.1 13.7 4.7 21.1 6.3 28.1 7.8 34.7 0.041 lbs 0.06 kg
L04BL858M Eagle Blue 85 --- 8mm 2.52" 64mm 3.1 13.7 4.7 21.1 6.3 28.1 7.8 34.7 0.041 lbs 0.06 kg
L04G898MS Eagle Green 89 --- 8mm 2.83" 72mm 5.1 22.8 8.4 37.4 11.5 51.3 14.4 64.1 0.04 lbs 0.06 kg
4905308 Eagle Green 89 Textured --- 8mm 2.83" 72mm 3.7 16.6 6.1 27.2 8.4 37.3 10.5 46.7 0.04 lbs 0.06 kg
4940024 Eagle Red 90 --- 8mm 3.15" 80mm 16.8 74.9 24.3 107.9 30.5 135.8 35.7 158.9 0.041 lbs 0.061 kg
L04BE958 Eagle Beige 95 --- 8mm 3.15" 80mm 13.6 60.5 19.3 85.7 24.1 107 28.1 125.1 0.042 lbs 0.062 kg
L04QC858M Eagle Clear 85 QC --- 8 x 3.2mm* 2.52" 64mm 1.3 5.8 2 9 2.7 12.1 3.4 14.9 0.034 lbs 0.051 kg
L04QR858M Eagle Red 85 QC --- 8 x 3.2mm* 2.52" 64mm 1.3 5.8 2 9 2.7 12.1 3.4 14.9 0.034 lbs 0.051 kg
L04QB858M Eagle Blue 85 QC --- 8 x 3.2mm* 2.52" 64mm 1.3 5.7 2 8.9 2.7 11.9 3.3 14.6 0.034 lbs 0.051 kg
L04CON8S QC Connectors 25/pack

* QC dimensions are shown O.D x I.D. (O.D. is the outer diameter of the belt. I.D. is the inner diameter of the belt.) Dimensions are for reference only.
