L04BL8515 by Fenner Drives | Eagle 85 Round Belting | 15mm Diameter | Non-Reinforced | Blue | 100ft
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Overview: | |||
|---|---|---|---|
|
|||
| Description: | |||
|
SPECIFICATIONS
| Profile Shape: | Round | Profile Size: | N/A |
|---|---|---|---|
| Reinforcement: | N/A | Color: | N/A |
| Compliancy: | N/A | Durometer: | N/A |
| Material: | N/A | Special Feature: | N/A |
| Package Length: | N/A |
| Part Number | Material & Color | Dimensions Ø | Minimum Pulley Ø | Working Load @ Percent Tension | Weight | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4% | 6% | 8% | 10% | ||||||||||||
| in | mm | in | mm | lbs | N | lbs | N | lbs | N | lbs | N | lbs/ft | kg/m | ||
| L04OP8015M | Eagle Opaque 80 | --- | 15mm | 4.13" | 105mm | 11.6 | 51.6 | 19.7 | 87.7 | 27.6 | 122.6 | 34.7 | 154.4 | 0.145 lbs | 0.216 kg |
| L04BL8515 | Eagle Blue 85 | --- | 15mm | 4.72" | 120mm | 10.8 | 48.1 | 16.7 | 74.2 | 22.2 | 99 | 27.4 | 121.9 | 0.142 lbs | 0.212 kg |
| L04G8915MS | Eagle Green 89 | --- | 15mm | 5.31" | 135mm | 18 | 80 | 29.5 | 131.4 | 40.6 | 180.5 | 50.7 | 225.5 | 0.141 lbs | 0.21 kg |
| 4905315 | Eagle Green 89 Textured | --- | 15mm | 5.31" | 135mm | 13.1 | 58.1 | 21.5 | 95.4 | 29.5 | 131.1 | 36.8 | 163.8 | 0.141 lbs | 0.21 kg |
| 4999315 | Eagle Red 90 | --- | 15mm | 5.91" | 150mm | 59.1 | 262.9 | 85.2 | 378.8 | 107.2 | 476.8 | 125.4 | 557.9 | 0.144 lbs | 0.214 kg |
| L04BE9515M | Eagle Beige 95 | --- | 15mm | 5.91" | 150mm | 47.8 | 212.5 | 67.7 | 301.2 | 84.6 | 376.2 | 98.9 | 440 | 0.146 lbs | 0.217 kg |
| 4941107 | Eagle Blue 80 MD | 5/8" | --- | 4.38" | 111mm | 8.4 | 37.5 | 13.1 | 58.2 | 17.4 | 77.6 | 21.7 | 96.4 | 0.149 lbs | 0.222 kg |
| 1032020 | Eagle Orange 85 | 5/8" | --- | 5" | 127mm | 12.1 | 53.9 | 18.7 | 83.1 | 24.9 | 110.8 | 30.7 | 136.5 | 0.16 lbs | 0.238 kg |
| 4908030 | Eagle Clear 85 | 5/8" | --- | 5" | 127mm | 12.1 | 53.9 | 18.7 | 83.1 | 24.9 | 110.8 | 30.7 | 136.5 | 0.16 lbs | 0.238 kg |
| 4907030 | Eagle Clear 95 | 5/8" | --- | 6.25" | 159mm | 22.7 | 100.9 | 33.7 | 149.8 | 43.2 | 192.3 | 51.4 | 228.7 | 0.164 lbs | 0.243 kg |
| 4934030 | Eagle Clear 85 QC | .625 x .273"* | --- | 5" | 127mm | 5 | 22.1 | 7.7 | 34.2 | 10.3 | 45.9 | 12.7 | 56.6 | 0.129 lbs | 0.192 kg |
| 4934020 | Eagle Yellow 85 QC | .625 x .273"* | --- | 5" | 127mm | 5 | 22.1 | 7.7 | 34.2 | 10.3 | 45.9 | 12.7 | 56.6 | 0.129 lbs | 0.192 kg |
| 4935030 | 15 per Pack | ||||||||||||||
* QC dimensions are shown O.D x I.D. (O.D. is the outer diameter of the belt. I.D. is the inner diameter of the belt.) Dimensions are for reference only.
