Sale price$57.62

Danfoss A/C & Refrigeration
E-Z Clip System - Male O-Ring (Short Pilot) with R134a Low Side Port - Straight

O-Ring Not Included. Clips & Cages Sold Separately.

For use with GH001 EverCool A/C & Refrigeration Hose.
Buy More, Save More!
Quantity Price Each
10–39 $54.16
40–79 $48.98
80+ $43.22
Discounts applied in cart/checkout.

Product Data:

Brand:
  • E-Z Clip
Shape:

Straight

Ends Configuration:
  • 5/8in Male O-Ring Short Pilot
  • 3/4in Hose Barb
Additional Information:
Steel
Part Number		 Thread
"T" 		Hose Size A Ref. D Ref. F Ref. Ref.

 Clip & Cage Kit
(Required)		 O-Ring Options
Neoprene Green HNBR
FJ3132-01-1010S 7/8-18 -10 4.43" 2.70" 0.63" 0.88" FF14173 22546-15 FF90178-15
FJ3132-02-1012S 7/8-18 -12 4.46" 2.70" 0.63" 0.88" FF14174 22546-15 FF90178-15

Danfoss (Eaton - Aeroquip)

Danfoss is a global technology leader in power management solutions that make electrical, hydraulic and mechanical power operate more efficiently, reliably, safely and sustainably. Danfoss hydraulic pumps, motors, transmissions, valves, cylinders, controls, hose and fittings offer a unique combination of proven technology and innovative design that translates directly into reliable performance and enhanced uptime.
