Sale price$163.78

Aeroquip® by Danfoss
100R2 TTC Reusable Hose Fitting - FC Series - Female 37° JIC Swivel - 45° Elbow

(Formerly Eaton Aeroquip)
Buy More, Save More!
Quantity Price Each
5–19 $153.95
20–59 $139.21
60+ $122.84
Discounts applied in cart/checkout.

Product Data:

Shape:

45 Degree

Ends Configuration:
  • 3/4in Female JIC
  • 3/4in Reusable Hose End
Material(s):
  • Steel
Technical Info:
Note:
  • For use with GH793 hose ONLY at SAE 100R2 pressures.
Steel
Part Number 		Hose Size Thread A D EØ H
FC5990-0404S -04 7/16-20 2.51" 1.34" 0.17" 0.33"
FC5990-0606S -06 9/16-18 2.82" 1.48" 0.31" 0.39"
FC5990-0808S -08 3/4-16 3.26" 1.75" 0.39" 0.55"
FC5990-1008S -08 - - - - -
FC5990-1212S -12 1-1/16-12 4.15" 2.28" 0.61" 0.78"
FC5990-1616S -16 1-5/16-12 5.03" 2.98" 0.82" 1.07"
