4S20DL8 Aeroquip by Danfoss | 4 Wire 4S Female DIN 24° Seat Swivel DKO (Light) (DL) Crimp Fitting | L30 Female DKO/DIN 24° Seat x -08 Hose Barb | Steel
4S20DL8 Aeroquip by Danfoss | 4 Wire 4S Female DIN 24° Seat Swivel DKO (Light) (DL) Crimp Fitting | L30 Female DKO/DIN 24° Seat x -08 Hose Barb | Steel
4S20DL8 Aeroquip by Danfoss | 4 Wire 4S Female DIN 24° Seat Swivel DKO (Light) (DL) Crimp Fitting | L30 Female DKO/DIN 24° Seat x -08 Hose Barb | Steel

4S20DL8 Aeroquip by Danfoss | 4 Wire 4S Female DIN 24° Seat Swivel DKO (Light) (DL) Crimp Fitting | L30 Female DKO/DIN 24° Seat x -08 Hose Barb | Steel

Sale price$72.55

Aeroquip® by Danfoss
4 Wire 4S Female DIN 24° Seat Swivel DKO (Light) Crimp Fitting (DL) - Straight
Buy More, Save More!
Quantity Price Each
20–39 $68.20
40–79 $61.67
80+ $54.41
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Aeroquip
Shape:

Straight

Ends Configuration:
  • L30 Female DIN
  • 1/2in Hose Barb
Technical Info:
Steel
Part Number 		Tube OD Hose Size Thread A D EØ Hex 1
DN Dash Size
4S8DL6 10 - -06 M16 x 1.5 1.99" 0.99" 0.26" 0.75"
4S10DL6 12 - -06 M18 x 1.5 2.01" 1.02" 0.26" 0.87"
4S12DL8 15 - -08 M22 x 1.5 2.30" 1.13" 0.38" 1.06"
4S16DL10 18 - -10 M26 x 1.5 2.33" 1.17" 0.50" 1.26"
4S20DL8 - - -08 M30X2 - - - -
4S20DL12 22 19 -12 M30X2 2.99" 1.56" 0.56" 36mm
4S25DL16 28 25 -16 M36X2 3.14" 1.59" 0.76" 41mm
4S32DL20 35 31 -20 M45X2 3.96" 1.79" 0.99" 50mm
