1" HPIII by Couplamatic | 2-Wire Domestic Hi-Pressure Extremely Flexible Hydraulic Hose | SAE 100R16 | 1" ID | 250ft
Couplamatic Systems Inc.
Two Wire Braid Hoses - HPIII Two Wire Domestic Hi-Pressure Extremely Flexible Hydraulic Hose - SAE 100R16
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $2,574.60 |
| 8–14 | $2,465.05 |
| 15+ | $2,191.15 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
2000
Specifications and Approvals:
Compatible Series:
| Applications: | High Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R16 |
|---|---|---|---|
| Cover: | Abrasion and Flame Resistant Cover, MSHA Approved | Reinforcement: | Two Wire Braids |
| Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Reel Footage |
|---|---|---|---|---|---|---|---|
| 1/4" HPIII | 1/4" | 0.541" | 5,000 lbs. | 20,000 lbs. | 2" | 18 lbs. | 250ft |
| 3/8" HPIII | 3/8" | 0.693" | 4,000 lbs. | 16,000 lbs. | 2.5" | 24 lbs. | 250ft |
| 1/2" HPIII | 1/2" | 0.823" | 3,500 lbs. | 14,000 lbs. | 3.5" | 31 lbs. | 250ft |
| 5/8" HPIII | 5/8" | 0.950" | 2,750 lbs. | 11,000 lbs. | 4" | 36 lbs. | 250ft |
| 3/4" HPIII | 3/4" | 1.103" | 2,250 lbs. | 9,000 lbs. | 4.8" | 49 lbs. | 250ft |
| 1" HPIII | 1" | 1.415" | 2,000 lbs. | 8,000 lbs. | 6" | 67 lbs. | 250ft |
