1/2" H7TLNC by Couplamatic | Twin Line Non-Conductive | Thermoplastic Hydraulic Hose | Polyester Braid | SAE 100R7 | 1/2" ID | 250ft
Couplamatic Systems Inc.
Polyester Braid - H7TLNC Non-Conductive Twin Line Thermoplastic Hydraulic Hose - (SAE 100R7)
Package Quantity: 250 FT
| Buy More, Save More! | |
| Quantity | Price Each |
| 4–7 | $2,115.72 |
| 8–14 | $2,025.69 |
| 15+ | $1,800.62 |
Discounts applied in cart/checkout.
Product Data:
Series:
Color(s):
Dash Size:
Internal Diameter:
Outer Diameter:
MAWP:
2000
Tubing Construction:
Cover Construction:
Specifications and Approvals:
Compatible Series:
| Applications: | Medium Pressure Hydraulics, Industrial or Agricultural | SAE Rating: | SAE 100R7 |
|---|---|---|---|
| Cover: | Orange Non-Conductive Polyurethane, Non-Perforated | Tube: | Nylon |
| Reinforcement: | Polyester Braid | Temperature: | -40F to +212F (-40C to +100C) |
| Part Number | Hose ID | Hose OD | Working Pressure (lbs) |
Min. Burst Pressure (lbs) |
Min. Bend Radius | Weight per 100ft | Coil Footage |
|---|---|---|---|---|---|---|---|
| 1/4" H7TLNC | 1/4" | 0.508" | 2,750 lbs. | 11,000 lbs. | 1.5" | 12 lbs. | 250ft |
| 5/16" H7TLNC | 5/16" | 0.585" | 2,500 lbs. | 10,000 lbs. | 1.75" | 16.6 lbs. | 250ft |
| 3/8" H7TLNC | 3/8" | 0.650" | 2,250 lbs. | 9,000 lbs. | 2" | 21 lbs. | 250ft |
| 1/2" H7TLNC | 1/2" | 0.815" | 2,000 lbs. | 8,000 lbs. | 3" | 34 lbs. | 250ft |
