01VS07OC050201 by AIGNEP | 01V Control Valves Series | 5/3 Open Center G-Thread 1/2" Double Solenoid Pilot Spring Centered | 24V DC/3W coil | Black Con
01VS07OC050201 by AIGNEP | 01V Control Valves Series | 5/3 Open Center G-Thread 1/2" Double Solenoid Pilot Spring Centered | 24V DC/3W coil | Black Con
AIGNEP

01VS07OC050201 by AIGNEP | 01V Control Valves Series | 5/3 Open Center G-Thread 1/2" Double Solenoid Pilot Spring Centered | 24V DC/3W coil | Black Con

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

SOLENOID PILOT VALVE
Technical Characteristics:
Operating Rating: 0 ÷ 10 bar
0 ÷ 145 psi		 Operating Pressure: Monostable: 2 ÷ 10 bar / 29 ÷ 145 psi
Bistable: 1 ÷ 10 bar / 14.5 ÷ 145 psi
Temperature: Min: 14°F (-10°C)
Max: 140°F (60°C)		 Component Parts and Materials: • Anodised and painted aluminium body
• Chemical nickel-plated spool
• NBR seals
Part Number (Black Con) Part Number (LED Con) Solenoid Voltage Minimum Power Ways Reactuation Function Size
01VS07OC020101 01VS07OC020102 12V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC020201 01VS07OC020202 24V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC020301 01VS07OC020302 24V DC 2W 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC020401 01VS07OC020402 24V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC020501 01VS07OC020502 110V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC020601 01VS07OC020602 220V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/8"
01VS07OC030101 01VS07OC030102 12V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC030201 01VS07OC030202 24V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC030301 01VS07OC030302 24V DC 2W 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC030401 01VS07OC030402 24V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC030501 01VS07OC030502 110V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC030601 01VS07OC030602 220V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/4"
01VS07OC050101 01VS07OC050102 12V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/2"
01VS07OC050201 01VS07OC050202 24V DC 3W 5/3 Monostable Spring Return Open Center (OC) G 1/2"
01VS07OC050301 01VS07OC050302 24V DC 2W 5/3 Monostable Spring Return Open Center (OC) G 1/2"
01VS07OC050401 01VS07OC050402 24V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/2"
01VS07OC050501 01VS07OC050502 110V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/2"
01VS07OC050601 01VS07OC050602 220V AC 5VA 5/3 Monostable Spring Return Open Center (OC) G 1/2"

AIGNEP

For over 40 years, AIGNEP has been a leading manufacturer of compressed air and industrial fluid fittings. Our products are widely known for their high quality and Italian design: pneumatic cylinders and solenoid valves, fluid process control valves “FLUIDITY”, compressed air pipeline “INFINITY”, fittings and quick couplings for every fluid media.
