W68LF-8-4R by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Threaded Fitting | 1/2" Connector x 1/4" Male BSPT Thread | .945" Width | Straight | Brass | Pack of 10
by Parker Hannifin
Push-to-Connect Fittings:W68LF Male Connector – BSPT
Package Quantity: 10 Units
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $156.65 |
| 20–59 | $141.65 |
| 60+ | $124.99 |
Discounts applied in cart/checkout.
Product Data:
Series:
Shape:
Straight
Ends Configuration:
Material(s):
Seal Material(s):
Special Properties:
| Product Features: |
|
|---|---|
| Markets: |
|
| Compatible Media: |
|
| Pressure Range: | Up to 290 PSI (19.9 bar) depending on tubing Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only) |
| Temperature Range: | -4° to +175° F (-20° to +79.4° C) 5° to +155° F (-15° to +68.3° C) (3/16” size only) |
| Vacuum Rating: | 28" Hg |
| Compatible Tubing: |
|
 |
||||||
|---|---|---|---|---|---|---|
| Part Number | Tube Size | BSPT (C) | F1 | F2 | H | K |
| W68LF-2-2R | 1/8" | 1/8" | 10 mm | 2 mm | .335" | .433 |
| W68LF-3-2R | 3/16" | 1/8" | 11 mm | 3 mm | .610" | .510 |
| W68LF-3-4R | 3/16" | 1/4" | 14 mm | 3 mm | .590" | .650 |
| W68LF-4-2R | 1/4" | 1/8" | 11 mm | 4 mm | .472" | .472 |
| W68LF-4-4R | 1/4" | 1/4" | 14 mm | 4 mm | .374" | .591 |
| W68LF-6-4R | 3/8" | 1/4" | 16 mm | 7 mm | .807" | .689 |
| W68LF-6-6R | 3/8" | 3/8" | 17 mm | 7 mm | .650" | .728 |
| W68LF-6-8R | 3/8" | 1/2" | 21 mm | 7 mm | .551" | .906 |
| W68LF-8-4R | 1/2" | 1/4" | 22 mm | 6 mm | 1.060" | .945 |
| W68LF-8-6R | 1/2" | 3/8" | 22 mm | 7 mm | 1.020" | .945 |
| W68LF-8-8R | 1/2" | 1/2" | 24 mm | 7 mm | .807" | 1.020 |
