V502SS-6-ACT by Parker | Rotary Actuator | 3/8" Size x 3/8" Female PTF Thread | 5.41" Length | Stainless Steel

V502SS-6-ACT by Parker | Rotary Actuator | 3/8" Size x 3/8" Female PTF Thread | 5.41" Length | Stainless Steel

Sale price$738.31

by Parker Hannifin
Ball Valves Rotary Actuator Series Act:Stainless Steel Rotary Actuator, Female Pipe Ends V502SS-X-ACT
Buy More, Save More!
Quantity Price Each
5–14 $694.01
15–29 $627.56
30+ $553.73
Discounts applied in cart/checkout.

Product Data:

Series:
  • V502SS Series
Shape:

No Orientation

Material(s):
  • Stainless Steel
Product Features:
  • One Piece Aluminum Extrusion Body
  • PTFE Seals
  • Stainless Steel Shaft
  • Self Lubricated Vane Seal
  • Anodized Aluminum Extrusion Vane
Specification:
Temperature Range: -40° to +180° F (-40° to +82.2° C)
Pressure Range:
  • Up to 250 PSI (17.2 bar)
  • Vacuum service 28 inches Hg
Part Number Size A Mtg. Holes B C D E F G Hex (H/I) J K (MPTF) L Flow Diameter Flow CV
V502SS-4-ACT 1/4" 1/4"-20 UNC 5.41" 4.61" 2.05" 2.07" 1.04" 1/4"-18 15/16" 10-24 1/8"-27 1.10" .375" 4.0"
V502SS-6-ACT 3/8" 1/4"-20 UNC 5.41" 4.61" 2.05" 2.07" 1.04" 3/8"-18 15/16" 10-24 1/8"-27 1.10" .375" 6.0"
V502SS-8-ACT 1/2" 1/4"-20 UNC 5.53" 4.64" 2.08" 2.27" 1.17" 1/2"-14 1-1/16" 10-24 1/8"-27 1.10" .500" 14.0"

*PTF Special Short. **PTF Special Extra Short
