V502P-4-ACT by Parker | Rotary Actuator | 1/4" Size x 1/4" Female PTF Thread | 5.25" Length | Aluminum
by Parker Hannifin
Ball Valves Rotary Actuator Series Act:Rotary Actuator, Female Pipe Ends V502P-X-ACT
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–14 | $796.10 |
| 15–29 | $719.88 |
| 30+ | $635.19 |
Discounts applied in cart/checkout.
Product Data:
Series:
Shape:
No Orientation
Material(s):
Seal Material(s):
Special Properties:
| Product Features: |
|
Specification: |
|---|---|
| Temperature Range: | -40° to +180° F (-40° to +82.2° C) |
| Pressure Range: |
|
 |
||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part Number | Size | A Mtg. Holes | B | C | D | E | F | G | Hex (H) | Hex (I) | J (UNC) | K (MPTF) | L | Flow Diameter | Flow CV | Min. Act Pressure (PSI) |
| V502P-4-ACT | 1/4" | 1/4-20 UNC | 5.25" | 4.47" | 1.91" | 2.03" | 1.00" | 1/4-18PTF | 15/16" | 15/16" | 10-24 | 1/8"-27 | 1.06" | .375" | 4.0" | 50 PSI |
| V502P-6-ACT | 3/8" | 1/4-20 UNC | 5.25" | 4.47" | 1.91" | 2.03" | 1.00" | 3/8-18PTF | 15/16" | 15/16" | 10-24 | 1/8"-27 | 1.06" | .375" | 5.8" | 50 PSI |
| V502P-8-ACT | 1/2" | 1/4-20 UNC | 5.38" | 4.54" | 1.98" | 2.20" | 1.09" | 1/2-14PTF* | 1-1/16" | 1-1/16" | 10-24 | 1/8"-27 | 1.19" | .500" | 12.0" | 50 PSI |
| V502P-12-ACT | 3/4" | 1/4-20 UNC | 5.57" | 4.63" | 2.07" | 2.42" | 1.29" | 3/4-14PTF** | 1-5/16" | 1-1/4" | 10-24 | 1/8"-27 | 1.38" | .685" | 25.0" | 75 PSI |
| V502P-16-ACT | 1" | 1/4-20 UNC | 5.85" | 4.76" | 2.20" | 2.75" | 1.38" | 1-11.5PTF | 1-9/16" | 1-1/2" | 10-24 | 1/8"-27 | 1.67" | .875" | 35.0" | 75 PSI |
*PTF Special Short. **PTF Special Extra Short
