TCR-T16-24 by Dixon Valve | True I.D. PTFE Hose Fitting | Sanitary Tri-Clamp | 1" Hose Size x 1-1/2" Clamp Size | 316 Stainless Steel

TCR-T16-24 by Dixon Valve | True I.D. PTFE Hose Fitting | Sanitary Tri-Clamp | 1" Hose Size x 1-1/2" Clamp Size | 316 Stainless Steel

Sale price$109.98
Buy more, save moreDiscounts applied in cart/checkout.
Use:
  • For use with True I.D. PTFE hoses.
316 Stainless Steel
Part Number		 Hose Size Clamp Size Crimp Collars for Convoluted Hose Crimp Collars for Smooth Bore Hose
Carbon Steel 304 Stainless Steel Carbon Steel 304 Stainless Steel
TCR-T08-24 1/2" 1-1/2" CSC-T08-1 SSC-T08-1 CSC-T08-2 SSC-T08-2
TCR-T12-24 3/4" 1-1/2" CSC-T12-1 SSC-T12-1 CSC-T12-2 SSC-T12-2
TCR-T16-16 1" 1" CSC-T16-1 SSC-T16-1 CSC-T16-2 SSC-T16-2
TCR-T16-24 1" 1-1/2" CSC-T16-1 SSC-T16-1 CSC-T16-2 SSC-T16-2
TCR-T24-24 1-1/2" 1-1/2" CSC-T24-1 SSC-T24-1 CSC-T24-2 -
TCR-T32-32 2" 2" CSC-T32-1 SSC-T32-1 - -

Additional Product Data:

Series:
  • TCR-T Series
Shape:

Straight

Ends Configuration:
  • 1in Hose Barb
  • 1-1/2in Sanitary Clamp End

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
