T253AA600X100 Alfagomma by Kuriyama | Layflat Water Discharge Hose | Black | 6" ID | 6.38" OD | 150 PSI | EPDM | 100ft Length
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
SPECIFICATIONS
| Application: | High pressure, 150 PSI lay flat type hose for general industrial construction and irrigation. | SAE Rating: | N/A |
|---|---|---|---|
| Other Ratings: | N/A | Tube: | Black EPDM. |
| Reinforcement: | High tensile textile cords. | Cover: | Black EPDM - abrasion and ozone-resistant. |
| Temperature Range: | -22 deg. F (-30 deg. C) to 176 deg. F (+80 deg. C) | Crimp Fittings: | N/A |
| Reusable Fittings: | N/A | Specifications | N/A |
| Other Features: | |||
|
|||
| Part Number | Nominal ID | Nominal OD | Max Rec. Working Pressure | Standard Length | Weight | ||
|---|---|---|---|---|---|---|---|
| (in.) | (mm) | (in.) | (mm) | PSI | (ft.) | (lbs./ft.) | |
| T253AA150X100 | 1-1/2" | 38mm | 1.81" | 46mm | 150 PSI | 100ft | 0.37 lbs |
| T253AA200X100 | 2" | 51mm | 2.32" | 59mm | 150 PSI | 100ft | 0.50 lbs |
| T253AA250X100 | 2-1/2" | 63mm | 2.80" | 71mm | 150 PSI | 100ft | 0.60 lbs |
| T253AA300X100 | 3" | 76mm | 3.31" | 84mm | 150 PSI | 100ft | 0.86 lbs |
| T253AA400X100 | 4" | 102mm | 4.33" | 110mm | 150 PSI | 100ft | 1.19 lbs |
| T253AA600X100 | 6" | 152mm | 6.38" | 162mm | 150 PSI | 100ft | 2.00 lbs |
| T253AA600X50 | 6" | 152mm | 6.38" | 162mm | 150 PSI | 50ft | 2.00 lbs |
| T253AA662X100* | 6-5/8" | 168mm | 7.01" | 178mm | 150 PSI | 100ft | 2.17 lbs |
| T253AA662X50* | 6-5/8" | 168mm | 7.01" | 178mm | 150 PSI | 50ft | 2.17 lbs |
| T253AA800X100 | 8" | 203mm | 8.46" | 215mm | 150 PSI | 100ft | 2.82 lbs |
| T253AA800X50 | 8" | 203mm | 8.46" | 215mm | 150 PSI | 50ft | 2.82 lbs |
| T253AA1000X100 | 10" | 254mm | 10.63" | 270mm | 150 PSI | 100ft | 5.11 lbs |
| T253AA1000X50 | 10" | 254mm | 10.63" | 270mm | 150 PSI | 50ft | 5.11 lbs |
| T253AA1200X50 | 12" | 305mm | 12.56" | 319mm | 150 PSI | 100ft | 5.93 lbs |
