Quality: |
- Certified by CSA International to comply with U.S. s3874, California AB1953, and similar laws of other states for the safe handling of drinking water
- 24h 100% seal test guaranteed
- Dual sealing system allows valve to be operated in either direction making installation easier
- No metal-to-metal moving parts
- Handle clearly shows ball position
- Silicone-free lubricant on all seals
- Chrome plated lead free brass ball for longer life
- Handle stops on body to avoid stresses at stem
|
|
Body: |
- Hot forged sand blasted, unplated lead free brass body and cap sealed with Loctite® or equivalent thread sealant
|
|
Stem: |
- Pure PTFE adjustable packing gland and reinforced PTFE washer for lower torque and easy maintenance
- Blowout-proof unplated lead free brass stem
|
|
Sealing: |
- Pure PTFE self-lubricating seats with flexible-lip design
|
|
Threads: |
- Solder-end ANSI B16.18 female by female connections
|
|
Flow: |
- Full port to DIN 3357 for maximum flow
|
|
Handle: |
- Geomet® carbon steel handle with thick PVC dip coating. Handle coating offers both thermal and electrical protection
- WARNING: do not exceed reasonable temperature and/or electrical load
- Handle removable with valve in service
|
|
Working Pressure & Temperature: |
- Maximum working pressure 600 PSI (CWP)
- -40°F/+350°F
- NSF 61 limits (CSA approval): tested for use in continuous exposure to water of ambient temperature
- WARNING: freezing of the fluid in the installation may severely damage the valve
|
|
Upon request: |
- Glass filled PTFE seals
- AISI 430 stainless steel handle
- Custom design
|
|
Approved by or in Compliance with: |
- GOST-R (Russia)
- Hygiene and epidemic center in Moscow city (Russia)
- Certified by CSA International for Drinking Water to NSF/ANSI 61 - NSF/ANSI 372 (USA)
- RoHS Compliant (EU)
- NOTE: approvals apply to specific configurations/sizes only.
|
|
| Part Number |
Size |
Dimensions (Inches) |
D
(Nominal) |
D
(Actual) |
DN |
I |
L |
G |
A |
H |
| T242D00 |
1/2" |
1/2" |
0.6271" |
0.590" |
0.492" |
2.244" |
1.181" |
3.937" |
1.695" |
| T242E00 |
3/4" |
3/4" |
0.8771" |
0.787" |
0.748" |
2.854" |
1.476" |
4.724" |
1.988" |
| T242F00 |
1" |
1" |
1.1279" |
0.984" |
0.905" |
3.346" |
1.673" |
4.724" |
2.153" |
| T242G00 |
1-1/4" |
1-1/4" |
1.3779" |
1.259" |
0.964" |
3.819" |
1.909" |
6.220" |
2.988" |
| T242H00 |
1-1/2" |
1-1/2" |
1.6279" |
1.574" |
1.102" |
4.488" |
2.244" |
6.220" |
3.236" |
| T242I00 |
2" |
2" |
2.1279" |
1.968" |
1.338" |
5.433" |
2.716" |
6.220" |
3.500" |
*DN shows the nominal flow diameter. Actual flow diameter complies with full port DIN 3357 part 4.
