SS304-E050 by Kuriyama | SS304-E Series | Part E | Cam & Groove Fitting | 1/2" Adapter x 1/2" Hose Barb | 304 Stainless Steel
Buy more, save moreDiscounts applied in cart/checkout.
What are the Applications?
- Kuriyama Camlock Couplings are intended for use in many industrial applications.
- Stainless steel is widely used for manufacturing fittings due to its strength, corrosion resistance, and ability to withstand extreme temperatures.
- An ideal option for food and beverage applications, which entail frequent, high temperature sanitation protocols.
- The durability and corrosion resistance also lend themselves to marine, oil and gas, and similarly demanding environments.
What are the Features?
- High quality design made to withstand rigorous applications found in industrial markets.
- Tri-Couple™ design available in 1 1/2", 2", 3", 4" sizes.
- Stainless steel alloy is analyzed on every melt, and specially designed for high tensile strength, rigidity, and impact resistance.
What are the Materials?
- ASTM stainless steel alloy.
- Complies with Mil-Spec A-A-59326 for material and interchangeability in relevant sizes.
| Part Number | Size (in) |
PSI Rating at 70°F |
ASTM Specification |
Weight Each (lbs) |
|---|---|---|---|---|
| SS304-E050 | 1/2" | 250 PSI | A666/304 | 0.25 lbs |
| SS304-E075 | 3/4" | 250 PSI | A666/304 | 0.36 lbs |
| SS304-E100 | 1" | 250 PSI | A666/304 | 0.60 lbs |
| SS304-E125 | 1-1/4" | 250 PSI | A666/304 | 0.95 lbs |
| SS304-E150* | 1-1/2" | 250 PSI | A666/304 | 1.22 lbs |
| SS304-E200* | 2" | 250 PSI | A666/304 | 1.98 lbs |
| SS304-E250 | 2-1/2" | 150 PSI | A666/304 | 2.64 lbs |
| SS304-E300* | 3" | 150 PSI | A666/304 | 3.90 lbs |
| SS304-E400* | 4" | 150 PSI | A666/304 | 6.38 lbs |
| SS304-E500 | 5" | 75 PSI | A666/304 | 9.10 lbs |
| SS304-E600 | 6" | 75 PSI | A666/304 | 13.49 lbs |
* Designates Tri-Couple fitting.
Additional Product Data:
Series:
MAWP:
250
Shape:
Straight
Cam & Groove Type:
Type E
Ends Configuration:
Material(s):
