SS-F100 by Kuriyama | SS-F Series | Part F | Cam & Groove Adapter | 1" Adapter x 1" Male NPT | 316 Stainless Steel
Buy more, save moreDiscounts applied in cart/checkout.
What are the Applications?
- Kuriyama Camlock Couplings are intended for use in many industrial applications.
- Stainless steel is widely used for manufacturing fittings due to its strength, corrosion resistance, and ability to withstand extreme temperatures.
- An ideal option for food and beverage applications, which entail frequent, high temperature sanitation protocols.
- The durability and corrosion resistance also lend themselves to marine, oil and gas, and similarly demanding environments.
What are the Features?
- High quality design made to withstand rigorous applications found in industrial markets.
- Stainless steel alloy is analyzed on every melt, and specially designed for high tensile strength, rigidity, and impact resistance.
What are the Materials?
- ASTM stainless steel alloy.
- Complies with Mil-Spec A-A-59326 for material and interchangeability in relevant sizes.
| Part Number | Size (in) |
PSI Rating at 70°F |
ASTM Specification |
Weight Each (lbs) |
|---|---|---|---|---|
| SS-F050 | 1/2" | 250 PSI | A666/316 | 0.30 lbs |
| SS-F075 | 3/4" | 250 PSI | A666/316 | 0.40 lbs |
| SS-F100 | 1" | 250 PSI | A666/316 | 0.56 lbs |
| SS-F125 | 1-1/4" | 250 PSI | A666/316 | 1.06 lbs |
| SS-F150 | 1-1/2" | 250 PSI | A666/316 | 1.28 lbs |
| SS-F200 | 2" | 250 PSI | A666/316 | 1.82 lbs |
| SS-F250 | 2-1/2" | 150 PSI | A666/316 | 2.68 lbs |
| SS-F300 | 3" | 150 PSI | A666/316 | 3.92 lbs |
| SS-F400 | 4" | 150 PSI | A666/316 | 6.32 lbs |
| SS-F500 | 5" | 75 PSI | A666/316 | 8.26 lbs |
| SS-F600 | 6" | 75 PSI | A666/316 | 11.27 lbs |
Additional Product Data:
Series:
MAWP:
250
Shape:
Straight
Cam & Groove Type:
Type F
Ends Configuration:
Material(s):
