RC150EZCR by Dixon Valve | EZ Boss-Lock Cam & Groove | Type C | 1-1/2" Coupler x 1-1/2" Hose Shank | 316 Stainless Steel

RC150EZCR by Dixon Valve | EZ Boss-Lock Cam & Groove | Type C | 1-1/2" Coupler x 1-1/2" Hose Shank | 316 Stainless Steel

Sale price$97.09

Dixon Valve & Coupling
EZ Boss-Lock Cam & Groove | Type C | Coupler x Hose Shank

Designed for use with liquids.

Suitable for use with King Crimp sleeves and ferrules.
Buy More, Save More!
Quantity Price Each
5–19 $91.26
20–59 $82.53
60+ $72.82
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Cam & Groove Type:

Type C

Ends Configuration:
  • 1-1/2in Female Cam & Groove
  • 1-1/2in Hose Barb
Features:
  • Resistant to accidental disconnection when dragged. The release lever opens in the direction opposite to the cam arm, so movements that tend to open the release lever also tend to close the cam arm.
  • Rotating action helps keep the locking device free of debris.
  • Designed to protect critical parts from impact and to withstand rugged use.
  • If the rotating lever is not flush with the handle, it is not properly engaged.
Construction:
  • Nitrile Rubber gasket.
Specifications:
  • Produced to interchange with all product produced to Commercial Item Description A-A-59326D.
Safety Notes:
  • Under no circumstances should cam and groove couplings be used for compressed air or steam service!
  • Under no circumstances should the EZ Boss-Lock cam arms be used on any fitting not specifically designed for their use.
  • Pressure rating recommendations are based on the use of mating Dixon fittings at ambient temperature 70°F / 21°C with a standard seal installed. For use at elevated temperature or other unusual operating conditions, consult Dixon.
  • Only use the crimp style shanks with the crimp style sleeves and ferrules. Due to differences in dimensions and tolerances for safety reasons, do not interchange other manufacturer's products with Dixon products.
How It Works:
  • To make a connection, simply slide the adapter into the coupler and with normal hand pressure, press the cam levers down.
  • Uncoupling is as quick and simple as coupling. Just lift the cam arms and remove the adapter.
  • No more fumbling with clamps, wire, clips or pins, just close the handles and the locking mechanism is engaged.
  • Extremely easy to open, the releaser lever is under your thumb when you want to open the fitting, ergonomic.
316 Stainless Steel
Part Number		 Hose I.D.
RC100EZCR 1"
RC125EZCR 1-1/4"
RC150EZCR 1-1/2"
RC200EZCR 2"
RC300EZCR 3"
RC400EZCR 4"
RC600EZCR 6"

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
