PSBJ731-4 by Parker | Pneumatic Threshold Sensor | 1/4" Male NPT Thread | 5/8" Hex | Straight | Bolt Material: Brass | Polymer

PSBJ731-4 by Parker | Pneumatic Threshold Sensor | 1/4" Male NPT Thread | 5/8" Hex | Straight | Bolt Material: Brass | Polymer

Sale price$56.15

by Parker Hannifin
Threshold Sensor Fittings:PSBJ731 Pneumatic Threshold Sensor - 5/32 Pilot
Buy More, Save More!
Quantity Price Each
20–39 $52.78
40–79 $47.73
80+ $42.11
Discounts applied in cart/checkout.

Product Data:

Series:
  • PSBJ731 Series
Shape:

Straight

Ends Configuration:
  • 1/4in Male NPT
  • 1/4in Female NPT
Product Features:
  • Polymer body
  • Brass screw
  • NBR seal
Markets:
  • Factory/Process Automation
  • Packaging
  • Petrochemical
  • Pneumatics
  • Semi-Conductor
Applications:
  • Robotics
  • Packaging
  • Textile
  • Machine Tools
  • Pneumatic Systems
Pressure Range: 45 to 115 PSI (3.1 to 7.9 bar)
Temperature Range: +5° to +140° F (-15° to +60° C)
Breaking Pressure: 8.5 PSI (0.5 bar)
Response Time: 3 MS
Model PSPE Pressure Range: 45 to 115 PSI (3.1 to 7.9 bar)
Breaking Pressure: 8.5 PSI (0.5 bar)
Current Rating: 5A/250VAC – 5W/48VDC
Compatible Tubing:
  • Semi-rigid nylon
  • Polyurethane 95 Durometer Shore A
  • Nylon
  • Fluoropolymer
Part Number NPT / UNF Hex H L
PSBJ731-0 10-32" 5/16" .62" 1.70"
PSBJ731-2 1/8" 9/16" .90" 1.74"
PSBJ731-4 1/4" 5/8" 1.09" 1.81"
PSBJ731-6 3/8" 7/8" 1.13" 1.91"

Parker Fluid System Connectors Division

Parker Fluid System Connectors Division delivers quality and service from design to delivery. Their engineers leverage advanced technology to create prototypes, refine designs, and improve manufacturing efficiencies, offering tailored solutions. ISO 9001 certified and focused on sustainability, they utilize recyclable materials and a brass chip recycling program to protect the environment and control costs. Flexible assembly, packaging, and shipping systems support diverse needs, including kitting and custom labeling, ensuring high-quality products and outstanding customer support.
