PGS600 by Dixon Valve | Process Gauge | Lower Mount | 4-1/2" Face | 1/2" Lower Mount | 0-600 PSI Range | Plastic

PGS600 by Dixon Valve | Process Gauge | Lower Mount | 4-1/2" Face | 1/2" Lower Mount | 0-600 PSI Range | Plastic

Sale price$146.77

Dixon Valve
Dixon® Gauge | Process Gauge | Lower Mount

Specifically designed for process, chemical, and petroleum industries, process gauges are engineered to deliver years of accurate service while withstanding vibration, corrosive media, and corrosive atmosphere.
Buy More, Save More!
Quantity Price Each
5–19 $137.96
20–59 $124.75
60+ $110.08
Discounts applied in cart/checkout.

Product Data:

Series:
  • PGS Series
Features:
  • Accuracy: ± 0.5% ANSI/ASME Grade 2A.
  • Scale: single scale PSI only.
Materials:
  • Case: black impact resistant thermoplastic, with safety blowout back, solid front, integral back flange (dry)
  • Ring: ethylene propylene
  • Wetted parts: 316L stainless steel
  • Window: poly carbonate
  • Dial: white aluminum
  • Pointer: black aluminum.
Specifications:
  • Temperature range: dry -40°F to 250°F (-40°C to 120°C)
Term Meanings:
  • Figure Interval: Figure Interval (Increments between PSI numbers on gauge face).
  • Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).
4-1/2" Face
1/2" Lower Mount
Part Number		 PSI Range Figure
Interval		 Minor
Gradient
PGS30 0-30 PSI 5 0.2
PGS60 0-60 PSI 10 0.5
PGS100 0-100 PSI 10 1
PGS160 0-160 PSI 20 1
PGS200 0-200 PSI 20 2
PGS300 0-300 PSI 50 2
PGS600 0-600 PSI 10 5
PGS1000 0-1000 PSI 100 10

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
