PGS30 by Dixon Valve | Process Gauge | Lower Mount | 4-1/2" Face | 1/2" Lower Mount | 0-30 PSI Range | Plastic

PGS30 by Dixon Valve | Process Gauge | Lower Mount | 4-1/2" Face | 1/2" Lower Mount | 0-30 PSI Range | Plastic

Sale price$146.31
Factory Order - Lead Time Applies
Buy more, save moreDiscounts applied in cart/checkout.
Features:
  • Accuracy: ± 0.5% ANSI/ASME Grade 2A.
  • Scale: single scale PSI only.
Materials:
  • Case: black impact resistant thermoplastic, with safety blowout back, solid front, integral back flange (dry)
  • Ring: ethylene propylene
  • Wetted parts: 316L stainless steel
  • Window: poly carbonate
  • Dial: white aluminum
  • Pointer: black aluminum.
Specifications:
  • Temperature range: dry -40°F to 250°F (-40°C to 120°C)
Term Meanings:
  • Figure Interval: Figure Interval (Increments between PSI numbers on gauge face).
  • Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).
4-1/2" Face
1/2" Lower Mount
Part Number		 PSI Range Figure
Interval		 Minor
Gradient
PGS30 0-30 PSI 5 0.2
PGS60 0-60 PSI 10 0.5
PGS100 0-100 PSI 10 1
PGS160 0-160 PSI 20 1
PGS200 0-200 PSI 20 2
PGS300 0-300 PSI 50 2
PGS600 0-600 PSI 10 5
PGS1000 0-1000 PSI 100 10

Additional Product Data:

Series:
  • PGS Series
