PBLSS800 Dixon Valve All Stainless Panel Builder Gauge - 2-1/2" Face, 1/4" Lower Back Mount - 0-800 PSI
Dixon

PBLSS800 Dixon Valve All Stainless Panel Builder Gauge - 2-1/2" Face, 1/4" Lower Back Mount - 0-800 PSI

Contact for Price

If you are interested in this item please fill out the Contact Form below.

Contact Us

How can we help you?

Price, availability, and details—available upon request.

Features:
  • Suitable for corrosive environments.
  • Used in gaseous and liquid media.
  • ASME B40.100 Grade A 2/1/2% full scale accuracy.
  • 316L stainless steel wetted parts materials.
  • Media temperature 212°F maximum.
  • Dial - white aluminum with black lettering; stop pin.
  • Pointer - black aluminum.
  • Glycerin filled case.
  • Laminated safety glass window lens.
  • Fits industry standard 2.56" panel hole cutout.
Part Number Fig. Inter. Grad Inter. Min/Max Temp PSI Weight (Lbs.)
PBLSS15 3 .2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-15 0.4785
PBLSS30 5 .5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-30 0.4865
PBLSS60 10 1 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-60 0.4800
PBLSS100 20 2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-100 0.6500
PBLSS160 20 2 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-160 0.4930
PBLSS200 50 5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-200 0.4900
PBLSS300 50 5 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-300 0.4850
PBLSS400 100 10 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-400 0.4900
PBLSS600 100 10 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-600 0.6600
PBLSS800 200 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-800 0.5000
PBLSS1000 200 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-1000 0.6500
PBLSS1500 300 20 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-1500 0.4785
PBLSS2000 500 50 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-2000 0.4850
PBLSS3000 500 50 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-3000 0.6800
PBLSS5000 1000 100 -4 deg. F / 140 deg. F (-20.00 deg. C / 60.00 deg. C) 0-5000 0.6500
