P6CLPR25M-60 by Flexco | #03531 | Clipper Combs for PRO-600 & PRO-6000 Lacer | Hook Size: 25 | 60" Belt Width

P6CLPR25M-60 by Flexco | #03531 | Clipper Combs for PRO-600 & PRO-6000 Lacer | Hook Size: 25 | 60" Belt Width

Sale price$6,147.22
Flexco Clipper® Production Lacers - Combs for Pro 600 and Pro 6000 Lacers
FREE SHIPPING DOMESTICALLY!
Buy More, Save More!
Quantity Price Each
3–5 $5,778.39
6+ $5,532.50
Discounts applied in cart/checkout.

Product Data:

Applicable Belt Width:

60in
Production Lacers are designed for high-volume production lacing. It's the quickest, most precise method of installing wire hooks. As the lacer jaws contact the hooks, the hook points penetrate the belt at the ideal angle, resulting in an optimal splice. Hook retainers/combs are available for all sizes of hooks, making production lacers capable of lacing any size Clipper® hook. All production lacers offer the continuous lacing feature which, with multiple operations, allows the user to lace belts wider than the width of the lacer.


Includes:
  • Comb
  • Gauge Pins
Applications:
  • Parcel services
  • General material handling
  • Corrugated box board
  • Food processing
  • Distribution centers
  • Ag/Combine pick-up belts
Features:
  • Pro 6000
    • Users of the hydraulic Pro 6000 install the ultimate splice. The jaws can be heated to ease hook penetration and to allow the belt cover to slightly flow, resulting in a splice with an extremely low profile. Lace 14" (350 mm) at a time, with combs available in lengths up to 60" (1500 mm). Longer combs allow the user to first load the fasteners into the comb, then lace up to 12" (300 mm) at a time, sliding the comb to the next section to be laced.
    • Lacer pressure can be adjusted up to 7350 PSI (500 bar), jaw closure hold time up to 10 seconds, and heated jaws up to 390 deg. F (200 deg. C).
    • Electronic controls permit users to program heat, pressure, and jaw closure times for repeatability in lacing procedures.
  • Pro 600
    • Includes all Pro 6000 features except the heated jaws.


Part Number Hook Size Belt Width
P6CLPR25M-24 25 24"
P6CLPR25M-36 25 36"
P6CLPR25M-48 25 48"
P6CLPR25M-60 25 60"
P6CLPR36M-24 36, UCM36, 30 24"
P6CLPR36M-36 36, UCM36, 30 36"
P6CLPR36M-48 36, UCM36, 30 48"
P6CLPR36M-60 36, UCM36, 30 60"
P6CLPR1M-24 1, UX1 24"
P6CLPR1M-36 1, UX1 36"
P6CLPR1M-48 1, UX1 48"
P6CLPR1M-60 1, UX1 60"
P6CLPR2M-24 2-7, U2-U7 24"
P6CLPR2M-36 2-7, U2-U7 36"
P6CLPR2M-48 2-7, U2-U7 48"
P6CLPR2M-60 2-7, U2-U7 60"

Flexco

From its inception, Flexco has focused on just one thing, maximising belt conveyor productivity. Whether you are a small farm in the Midwestern United States, or a large mine in eastern Europe, or a global parcel handling operation with facilities around the world, we are focused on becoming your number one resource for products and services that maximise your belt conveyor uptime, productivity, and safety.
