HUT206-2 by Kuriyama | Figure 206 | Threaded Hammer Union | 2000 PSI | CWP | 2" Female NPT x 2" Female NPT | Buna-N

HUT206-2 by Kuriyama | Figure 206 | Threaded Hammer Union | 2000 PSI | CWP | 2" Female NPT x 2" Female NPT | Buna-N

Sale price$60.48

Kuriyama Couplings™ - Hammer Unions - Figure 206 - Threaded Female NPT x Female NPT - 2000 PSI CWP

Buy More, Save More!
Quantity Price Each
10–39 $56.85
40–79 $51.41
80+ $45.36
Discounts applied in cart/checkout.

Product Data:

Shape:

Straight

Ends Configuration:
  • 2in Female NPT
  • 2in Female NPT
Material(s):
  • Ductile Iron
Applications:
  • Applications include oil, gas, air, and water.
  • For use with Kuriyama Hoses
Features:
  • General Purpose Union With O-Ring in Male Sub for Improved Sealing
  • Unions conform to NACE, ISO and DNV standards.
  • Color coded for easy identification.
  • CWP (Cold Working Pressure) is the maximum pressure at 70 deg. F (+21 deg. C).
  • Unions are completely interchangeable with competitors of like products.
Materials:
  • ASTM Grade 65-45-12
  • ASTM A-105
  • ASTM A29
  • NPT threads conform to ASME B1.20.1
  • Elastomer seals are BUNA-N
Part Number Size Weight (Lbs.)
HUT206-2 2" x 2" 4.60 lbs
HUT206-3 3" x 3" 11.80 lbs
HUT206-4 4" x 4" 19.10 lbs
HUT206-6 6" x 6" 45.00 lbs
HUT206-8 8" x 8" 66.00 lbs

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
