HSGP400CCA Dixon Valve HSG Sight Glass - 4" Bolted Clamp Style - PTFE Gasket - 316L Stainless Steel

HSGP400CCA Dixon Valve HSG Sight Glass - 4" Bolted Clamp Style - PTFE Gasket - 316L Stainless Steel

Sale price$615.07

Dixon Sanitary Fittings HSG Sight Glass - Bolted Clamp Style - PTFE Gasket - 316L Stainless Steel

Used widely in the food, dairy, and beverage sanitary processes to view fluids.

Can be used in industrial applications when you want to CIP and require 316L stainless steel construction.
Buy More, Save More!
Quantity Price Each
5–14 $578.17
15–29 $522.81
30+ $461.30
Discounts applied in cart/checkout.

Product Data:
Features:
  • Easy assembly and disassembly
  • Clamp connection standard
  • Higher pressure range than other sight glasses
  • Rubber seals are I-line gasket
  • Clamp protects glass from getting damaged
  • Patent pending assembly design
Construction:
  • Body: 316L stainless steel
  • Sight glass: Polycarbonate
  • Gaskets: PTFE (PTFE supplied with bolted clamp)
  • 3A Certified for CIP
Part Number Tube OD Max. Operating Pressure
HSGP050CCA 1/2" 500 PSI @ 70°F
300 PSI @ 200°F
HSGP075CCA 3/4" 500 PSI @ 70°F
300 PSI @ 200°F
HSGP100CCA 1" 500 PSI @ 70°F
300 PSI @ 200°F
HSGP150CCA 1-1/2" 450 PSI @ 70°F
250 PSI @ 200°F
HSGP200CCA 2" 400 PSI @ 70°F
200 PSI @ 200°F
HSGP250CCA 2-1/2" 350 PSI @ 70°F
175 PSI @ 200°F
HSGP300CCA 3" 250 PSI @ 70°F
125 PSI @ 200°F
HSGP400CCA 4" 80 PSI @ 70°F

40 PSI @ 200°F
HSGP600CCA 6" 50 PSI @ 70°F
25 PSI @ 200°F

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
