GTA50C1-2.0-200N by Texcel | GAMMA™-FLEX TANK 500 Series | Heavy-Duty Corrugated Tank Truck Hose | 2" Hose ID | 500 PSI | 29 in/Hg Vacuum Rated | Black
GAMMA™ by Texcel
FLEX TANK 500 Series | 500psi Heavy-Duty Corrugated Tank Truck Hose
Purchased Lengths of hose will be multiple pieces unless Product Option or Title specifies Exact Length.
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $38.09 |
| 40–79 | $34.44 |
| 80+ | $30.39 |
Discounts applied in cart/checkout.
Product Data:
Brand:
Series:
Color(s):
Internal Diameter:
Outer Diameter:
Tubing Construction:
Cover Construction:
| Technical Data: | |||
|---|---|---|---|
| Description: | Heavy-duty and high pressure tank truck hose for the most demanding applications. | Tube: | Black, Nitrile, 55% aromatics (ORS) |
| Cover: | Black, Neoprene (corrugated) | Reinforcement: | High tensile tire cord plies; dual helix wire |
| Safety Factor: | 4:1 | Temperature: | -40°F to +180°F |
| Branding: | TEXCEL® GAMMA™-CORR TANK 500 - HEAVY DUTY TANK TRUCK HOSE 500 PSI W.P | ||
| Part Number | Hose ID | Hose OD | Working Pressure (psi) | Vacuum (in./HG) | Bend Radius | Lbs./ft |
|---|---|---|---|---|---|---|
| GTA50C1-2.0-200N | 2" | 2-50/64" | 500 psi | 29 | 6" | 1.73 lbs |
| GTA50C1-3.0-200N | 3" | 3-59/64" | 500 psi | 29 | 9" | 2.77 lbs |
| GTA50C1-4.0-200N | 4" | 5-2/64" | 500 psi | 29 | 13" | 4.36 lbs |
