GL360FG FlutterGuard™ by Dixon Valve | Dry Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-1500 PSI Range | ABS Plastic

GL360FG FlutterGuard™ by Dixon Valve | Dry Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-1500 PSI Range | ABS Plastic

Sale price$42.03

Dixon Valve
Dixon® Gauge | FlutterGuard™ | Dry Gauge | Lower Mount

FlutterGuard virtually eliminates pointer flutter, making the gauge easier to read and reducing excessive movement wear, liquid-free casing results in lighter weight and eliminates the chance of gauge leakage.
Buy More, Save More!
Quantity Price Each
10–39 $39.51
40–79 $35.73
80+ $31.52
Discounts applied in cart/checkout.

Product Data:

Brand:
  • FlutterGuard
Series:
  • GL-FG
Features:
  • ASME B40.1, Grade B (± 3-2-3% accuracy).
  • PowerFlex™ movement with polyester segment, designed to resist the effects of shock, vibration, and pulsation.
Materials:
  • Window: poly carbonate
  • Pointer: black aluminum
  • Case: ABS plastic, corrosion resistant
Specifications:
  • Ambient temperature range of -40°F to 150°F (-40°C to 66°C)
  • C-shaped bronze safety bourdon tube (600 PSI gauges and lower)
  • Helical wound bronze safety bourdon tube (1,000 PSI gauges and higher)
Term Meanings:
  • Figure Interval: Figure Interval (Increments between PSI numbers on gauge face).
  • Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).
2-1/2" Face
1/4" Lower Mount
Part Number		 PSI Range Figure
Interval		 Minor
Gradient
GL300FG 0-15 PSI 1 0.5
GL320FG 0-30 PSI 5 0.5
GL325FG 0-60 PSI 5 1
GL330FG 0-100 PSI 10 2
GL335FG 0-160 PSI 20 5
GL340FG 0-200 PSI 20 5
GL345FG 0-300 PSI 30 5
GL347FG 0-400 PSI 50 10
GL350FG 0-600 PSI 50 10
GL355FG 0-1000 PSI 200 20
GL360FG 0-1500 PSI 300 50
GL365FG 0-2000 PSI 400 50
GL370FG 0-3000 PSI 500 100
GL375FG 0-5000 PSI 1000 100
