GBRW200 by Dixon Valve | Welding Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-200 PSI Range | Brass

GBRW200 by Dixon Valve | Welding Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-200 PSI Range | Brass

Sale price$63.08
Factory Order - Lead Time Applies
Buy more, save moreDiscounts applied in cart/checkout.
Features:
  • ± 3-2-3% accuracy according to ASME B40.100 Grade B.
  • "USE NO OIL" written in red on face.
Materials:
  • Case: polished drawn stainless steel
  • Window: twist-lock polycarbonate
  • Bourdon tube: copper alloy
Specifications:
  • Ambient temperature range: -40°F to 140°F (-20°C to 60°C)
Term Meanings:
  • Figure Interval: Figure Interval (Increments between PSI numbers on gauge face).
  • Gradient Interval: Graduation Interval (Fractional increments between PSI numbers on gauge face).
2-1/2" Face
1/4" Lower Mount
Part Number		 PSI Range Figure
Interval 		Minor
Gradient
GBRW30 0-30 PSI 5 0.5
GBRW30R* 0-30 PSI 5 0.5
GBRW60 0-60 PSI 10 1
GBRW100 0-100 PSI 20 2
GBRW200 0-200 PSI 50 5
GBRW400 0-400 PSI 100 10
GBRW600 0-600 PSI 100 10
GBRW4000 0-4000 PSI 500 100

* Red band between 15 to 30 PSI

Additional Product Data:

Series:
  • GBRW Series

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
