GBCUFF200 by Kuriyama | Grease Bandit™ | GBAND™ Series | Cuff for Grease Trap Hose | 2" Hose ID
Minimum Order Quantity: 5 Units
Buy more, save moreDiscounts applied in cart/checkout.
Grease & Oil Transfer Hose
Kuriyama GBAND Grease & Oil Transfer Hose
Corrugated, crush-resistant hose with a grease- and oil-resistant liner, built for food oil transfer and grease trap pump-out.
1
What is this product used for?
- Food oil transfer
- Grease traps
2
What are the key specifications?
Tube
Proprietary oil resistant inner liner
Cover
HDPE outer cover
Service Temperature Range
-40°F (-40°C) to +150°F (+65°C) — actual range is application dependent
3
What are the main product features?
- Grease Resistant — Proprietary, oil resistant liner specifically designed to withstand the damaging effects of grease. Won't dry out and crack like other hoses.
- Superior Flexibility — Corrugated tube and ribs provide high flexibility, perfect for maneuvering in tight areas.
- “Cold-Flex” Materials — Hose remains flexible in sub-zero temperatures.
- Crush Resistant — Will spring back to original shape after being crushed, will not kink.
- Easy Slide Helix — Exposed ribs protect hose tube from cover wear, and allow hose to slide easily over rough surfaces. Easy to handle.
4
Which sizes are available?
| Part Number 25ft |
Part Number 30ft |
Part Number 50ft |
Nominal ID (in) | Nominal ID (mm) | Nominal OD (in) | Nominal OD (mm) | Vacuum Rating @68°F |
Min. Bend Radius @68°F |
Cuff |
|---|---|---|---|---|---|---|---|---|---|
| — | GBAND150X30 | GBAND150X50 | 1-1/2" | 38.1mm | 1.90" | 48.3mm | 23 in. Hg | 1" | GBCUFF150 |
| GBAND200X25 | GBAND200X30 | GBAND200X50 | 2" | 50.8mm | 2.40" | 61mm | 17 in. Hg | 1.75" | GBCUFF200 |
Service life may vary depending on operating conditions and the type of material being conveyed.
Additional Product Data:
Brand:
Series:
Shape:
Straight
