FWV10S10S Dixon Cast Aluminum Forestry Grade 1/4 Turn Ball Type Wye Valve - 1" Female NPSH x (two) 1" Male NPSH

FWV10S10S Dixon Cast Aluminum Forestry Grade 1/4 Turn Ball Type Wye Valve - 1" Female NPSH x (two) 1" Male NPSH

Sale price$551.36

Dixon Fire Fittings
Fire Valves / Building Connections - Forestry Grade 1/4 Turn Ball Type Wye Valve

Built to United States Forest Service specifications.
Buy More, Save More!
Quantity Price Each
5–14 $518.28
15–29 $468.66
30+ $413.52
Discounts applied in cart/checkout.

Product Data:

Shape:

Y

Ends Configuration:
  • 1in Female NPSH
  • 1in Male NPSH
  • 1in Male NPSH
  • Some Ends Match
Material(s):
  • Aluminum
Features:
  • Cast aluminum swivel inlet, anodized body, hard-coated threads.
  • 1" and 1-1/2" for use up to 600 PSI (water/AFFF only); 2-1/2" for use up to 400 PSI (water/AFFF only).
Part Number Female Thread Two Male Threads Weight
(Lbs.)
FWV10S10S 1" NPSH 1" NPSH 1.7900
FWV15S15S 1-1/2" NPSH 1-1/2" NPSH 3.3500
FWV15F15F* 1-1/2" NH (NST) 1-1/2" NH (NST) 3.6600
FWV25F15F 2-1/2" NH (NST) 1-1/2" NH (NST) 4.0700
FWV25F25F 2-1/2" NH (NST) 2-1/2" NH (NST) 11.3250

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
