FC321-08 Aeroquip by Danfoss | LPG Stainless Steel Wire Braided Transportation Hose | 0.41" ID
Aeroquip® by Danfoss
FC321 Series | LPG Stainless Steel Wire Braided Transportation Hose
Purchased Lengths of hose will be multiple pieces unless Product Option or Title specifies Exact Length.
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $16.01 |
| 40–79 | $14.48 |
| 80+ | $12.77 |
Product Data:
350
| Hose Properties: | |||
|---|---|---|---|
| Application: | Designed for butane-propane applications on either mobile or stationary equipment. | SAE Ratings: | N/A |
| Other Ratings: | Meets: UL Listing MH6044 | Tube: | Synthetic Rubber |
| Reinforcement: | Textile Inner Braid, a Stainless Steel Wire Braid | Cover: | Synthetic Rubber Impregnated Textile Braid |
| Operating Parameters: | -40°F to +250°F (-40°C to +121°C) | ||
WARNING: LPG is a very hazardous liquid or gas and should be handled with maximum care to prevent leakage. Since the gas is heavier than air, it may flow along the ground if it escapes and cause an explosion or a fire. No leakage should ever be tolerated.
| Part Number | Hose ID | Hose OD | Max. Operating Pressure | Min. Burst Pressure | Min. Bend Radius | Weight | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| mm | in | mm | in | bar | psi | bar | psi | mm | in | kg/m | lbs/ft | |
| FC321-04 | 4,8mm | 0.19" | 13,2mm | 0.52" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 38,1mm | 1.50" | 0,16 kg/m | 0.11 lbs/ft |
| FC321-05 | - | 0.25" | - | 0.58" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | - | 1.75" | - | 0.13 lbs/ft |
| FC321-06 | 7,9mm | 0.31" | 17,0mm | 0.67" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 50,8mm | 2.00" | 0,27 kg/m | 0.18 lbs/ft |
| FC234-08 | 10,4mm | 0.41" | 19,6mm | 0.77" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 58,7mm | 2.31" | 0,31 kg/m | 0.21 lbs/ft |
| FC321-10 | 12,7mm | 0.50" | 23,4mm | 0.92" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 69,9mm | 2.75" | 0,43 kg/m | 0.29 lbs/ft |
| FC321-12 | 16,0mm | 0.63" | 27,4mm | 1.08" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 82,6mm | 3.25" | 0,55 kg/m | 0.37 lbs/ft |
| FC321-16 | 22,4mm | 0.88" | 31,5mm | 1.24" | 24,0 bar | 350 psi | 122,0 bar | 1750 psi | 93,7mm | 3.69 " | 0,56 kg/m | 0.38 lbs/ft |
Bulk / By the Foot: We sell Danfoss hose in "Bulk Length" unless otherwise specified in the title or option selector as "Exact Length". When you buy "Bulk Length" hose you are agreeing to buy multiple lengths that add up to the length you purchased. If your length can be supplied as a single piece then it will be, but there can be no assurance of this even if you contact us. If you need a single piece then you can select an "Exact Length" option or Contact Us for a quote.
Warning! Danfoss hose and fittings are engineered to match Danfoss Aeroquip hose and fitting tolerances. The use of Danfoss fittings on hose supplied by other manufacturers may result in the production of unreliable and unsafe hose assemblies and is neither recommended or authorized by Danfoss Corporation, Murdock Industrial Inc., or any other entity. Consult current master catalog for additional warnings and cautions.
