DG1000 by Dixon Valve | General Purpose Digital Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-1000 PSI Range | ABS Plastic

DG1000 by Dixon Valve | General Purpose Digital Gauge | Lower Mount | 2-1/2" Face | 1/4" Lower Mount | 0-1000 PSI Range | ABS Plastic

Sale price$616.45
Factory Order - Lead Time Applies
Buy more, save moreDiscounts applied in cart/checkout.
Features:
  • 0.5% terminal point accuracy.
  • Five-digit LCD display with large size .48" characters.
  • Bar graph display (20 segment).
  • Nine engineering units (accessed through keypad): PSI, in. HG, cm Hg, mm Hg, KPA, Mpa, BAR, KG/cm2, ft H20.
  • IP67 weatherproof enclosure, polycarbonate / ABS.
  • Two AA alkaline batteries included.
  • 2,000 hour minimum battery life.
Materials:
  • Wetted parts: 17-4 PH stainless steel sensor with 316L stainless steel socket.
Specifications:
  • Operating temperature: -4°F to 140°F (-20°C to 60°C)
  • Polycarbonate window
2-1/2" Face
1/4" Lower Mount
Part Number		 PSI Range
DG100 0-100 PSI
DG300 0-300 PSI
DG1000 0-1000 PSI
DG10000 0-10000 PSI

Additional Product Data:

Series:
  • DG Series

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.

Explore Dixon Valve & Coupling
