CSRFTHD1500250 by Kuriyama | CSRFTHD Series | Raised Face Threaded 4-Hole Flange 150# | 2-1/2" Female NPT | 7" OD | Bore: 2.940" | Thickness: 1-1/8" | Carbon Steel
Kuriyama of America Inc.
CSRFTHD Series | Raised Face Female NPT Threaded Flange 150# | Carbon Steel
Designed for use in low-pressure applications in noncorrosive environments.
Designed with female NPT threads for use with male threaded fittings.
| Buy More, Save More! | |
| Quantity | Price Each |
| 10–39 | $43.84 |
| 40–79 | $39.64 |
| 80+ | $34.98 |
Discounts applied in cart/checkout.
What are the Applications?
- Designed for use in low-pressure applications in noncorrosive environments.
What are the Features?
- Designed with female NPT threads for use with male threaded fittings.
What are the Materials?
- Forged Carbon Steel
- ANSI B16.56
- ASTM A-105
 |
|||||||||
|---|---|---|---|---|---|---|---|---|---|
| Part Number | Size (in) |
OD A (in) |
Bore B | Circle C (in) |
Thickness (in) |
Number Bolt Holes |
Diameter Bolt Holes (in) |
PSI Rating at 70?F |
Weight Each (lbs) |
| CSRFTHD1500150 | 1-1/2" | 5" | 1.950" | 3-7/8" | 7/8" | 4 | 5/8" | 150 PSI | 3.60 lbs |
| CSRFTHD1500200 | 2" | 6" | 2.440" | 4-3/4" | 1" | 4 | 3/4" | 150 PSI | 5.07 lbs |
| CSRFTHD1500250 | 2-1/2" | 7" | 2.940" | 5-1/2" | 1-1/8" | 4 | 3/4 | 150 PSI | 7.05 lbs |
| CSRFTHD1500300 | 3" | 7-1/2" | 3.570" | 6" | 1-1/4" | 4 | 3/4 | 150 PSI | 7.94 lbs |
| CSRFTHD1500400 | 4" | 9" | 4.570" | 7-1/2" | 1-3/8" | 8 | 3/4" | 150 PSI | 13.01 lbs |
| CSRFTHD1500600 | 6" | 11" | 6.720" | 9-1/2" | 1-1/2" | 8 | 7/8" | 150 PSI | 18.74 lbs |
| CSRFTHD1500800 | 8" | 13-1/2" | 8.720" | 11-3/4" | 1-3/4" | 8 | 7/8" | 150 PSI | 29.98 lbs |
| CSRFTHD1501000 | 10" | 16" | 10.880" | 14-1/4" | 2" | 12 | 1" | 150 PSI | 42.99 lbs |
| CSRFTHD1501200 | 12" | 19" | 12.880" | 17" | 2-1/8" | 12 | 1" | 150 PSI | 63.93 lbs |
Product Data:
Series:
MAWP:
150
Shape:
Straight
Ends Configuration:
Material(s):
Specifications and Approvals:
