Y007 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1-1/2" Female NPT x 1-1/2" Female NPT | Cast Iron

Y007 by Dixon Valve | Y Line Strainer | 20 x 20 Mesh Screen | 1-1/2" Female NPT x 1-1/2" Female NPT | Cast Iron

Sale price$140.07

Dixon Valve
Y Line Strainer | Cast Iron
Buy More, Save More!
Quantity Price Each
5–19 $131.67
20–59 $119.06
60+ $105.05
Discounts applied in cart/checkout.

Product Data:

Shape:

Y

Ends Configuration:
  • 1-1/2in Female NPT
  • 1-1/2in Female NPT
  • Some Ends Match
Material(s):
  • Iron
Features:
  • Plug ported for blowdown service.
  • No replacement screens available.
Material:
  • Body: Cast Iron
  • Graphite gasket
Specification:
  • Working pressure: 500 PSI CWP; 250 PSI SWP
  • Maximum temperature: 406°F (208°C)
Cast Iron
Part Number		 Female NPT Mesh Type
Y001 1/4" 20 x 20 Mesh
Y002 3/8" 20 x 20 Mesh
Y003 1/2" 20 x 20 Mesh
Y004 3/4" 20 x 20 Mesh
Y005 1" 20 x 20 Mesh
Y006 1-1/4" 20 x 20 Mesh
Y007 1-1/2" 20 x 20 Mesh
Y008 2" 20 x 20 Mesh
