W68LF-14M-6R by Parker | Prestolok PLP Composite Push-to-Connect Fittings | Threaded Fitting | 14mm Connector x 3/8" Male BSPT Thread | 24mm Width | Straight | Brass | Pack of 10
by Parker Hannifin
Push-to-Connect Fittings:W68LF Male Connector Metric to BSPT
Package Quantity: 10 Units
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $129.71 |
| 20–59 | $117.29 |
| 60+ | $103.49 |
Discounts applied in cart/checkout.
Product Data:
Series:
Shape:
Straight
Ends Configuration:
Material(s):
Seal Material(s):
Special Properties:
| Product Features: |
|
|---|---|
| Markets: |
|
| Compatible Media: |
|
| Pressure Range: | Up to 290 PSI (19.9 bar) depending on tubing Up to 260 PSI (17.9 bar) depending on tubing (3/16” size only) |
| Temperature Range: | -4° to +175° F (-20° to +79.4° C) 5° to +155° F (-15° to +68.3° C) (3/16” size only) |
| Vacuum Rating: | 28" Hg |
| Compatible Tubing: |
|
 |
||||||
|---|---|---|---|---|---|---|
| Part Number | Tube Size | BSPT (C) | F1 | F2 | H | K |
| W68LF-4M-2R | 4 mm | 1/8" | 10 mm | 3 mm | 9.5 mm | 11.0 mm |
| W68LF-4M-4R | 4 mm | 1/4" | 14 mm | 3 mm | 6.5 mm | 15.0 mm |
| W68LF-4M-6R | 4 mm | 3/8" | 17 mm | 3 mm | 8.0 mm | 18.5 mm |
| W68LF-6M-2R | 6 mm | 1/8" | 11 mm | 4 mm | 11.5 mm | 11.0 mm |
| W68LF-6M-4R | 6 mm | 1/4" | 14 mm | 4 mm | 8.5 mm | 15.0 mm |
| W68LF-6M-6R | 6 mm | 3/8" | 17 mm | 4 mm | 8.5 mm | 18.5 mm |
| W68LF-6M-8R | 6 mm | 1/2" | 21 mm | 4 mm | 9.0 mm | 23.0 mm |
| W68LF-8M-2R | 8 mm | 1/8" | 13 mm | 5 mm | 20.0 mm | 14.0 mm |
| W68LF-8M-4R | 8 mm | 1/4" | 14 mm | 6 mm | 17.0 mm | 15.0 mm |
| W68LF-8M-8R | 8 mm | 1/2" | 21 mm | 6 mm | 12.0 mm | 23.0 mm |
| W68LF-10M-2R | 10 mm | 1/8" | 16 mm | 5 mm | 22.5 mm | 17.5 mm |
| W68LF-10M-4R | 10 mm | 1/4" | 16 mm | 7 mm | 20.0 mm | 17.5 mm |
| W68LF-10M-6R | 10 mm | 3/8" | 17 mm | 8 mm | 16.5 mm | 18.5 mm |
| W68LF-10M-8R | 10 mm | 1/2" | 21 mm | 8 mm | 14.0 mm | 23.0 mm |
| W68LF-12M-4R | 12 mm | 1/4" | 19 mm | 7 mm | 26.5 mm | 21.0 mm |
| W68LF-12M-6R | 12 mm | 3/8" | 19 mm | 9 mm | 24.0 mm | 211.0 mm |
| W68LF-12M-8R | 12 mm | 1/2" | 21 mm | 9 mm | 19.5 mm | 23.0 mm |
| W68LF-14M-6R | 14 mm | 3/8" | 22 mm | 9 mm | 28.5 mm | 24.0 mm |
| W68LF-14M-8R | 14 mm | 1/2" | 24 mm | 10 mm | 23.5 mm | 26.0 mm |
