TSFE14-0312-062.10 Versilon™ by Saint Gobain | FEP | High-Performance Transparent Fluoropolymer Tubing | 3/16" ID x 5/16" OD x .062" Wall | 100' Package Length
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
Versilon® FEP Tubing
Saint-Gobain's Versilon® FEP tubing is transparent, high-performance fluoropolymer tubing with excellent physical and chemical resistance. A chemically inert thermoplastic, Versilon® tubing offers high purity. Versilon® FEP tubing is non-corroding, non-oxidizing, not affected by nearly all solvents, acids and fuels.
1
What is this product used for?
- Automotive
- Printing Press
- Heat Exchange
- Laboratory and Measurement Technologies
- Other Chemical Transfer Applications
2
What are the key specifications?
Fluoropolymer
Fluoropolymer
None
Transparent
+402°F (+206°C)
-328°F (-200°C)
FDA regulation 21 CFR 177.1550
Not intended as an implant material!
3
What are the main product features?
- Excellent physical and electrical properties.
- Outstanding chemical resistance.
- Wide temperature range, up to +206°C.
- Chemically inert.
- Transparent tube.
- Non-corroding and non-aging.
- UV resistance.
4
Which sizes or configurations are available?
| Part Number |
Inside Diameter |
Outside Diameter |
Wall Thickness |
Bend Radius |
Max. Working Pressure at 73° F |
|
|---|---|---|---|---|---|---|
| (50ft Lengths) | (100ft Lengths) | in | in | in | in | PSI |
| TSFE14-0125-031-50 | TSFE14-0125-031.10 | 1/16" | 1/8" | .031" | 1/2" | 196 PSI |
| TSFE14-0156-031-50 | TSFE14-0156-031.10 | 3/32" | 5/32" | .031" | N/A | N/A |
| TSFE14-0250-062-50 | TSFE14-0250-062.10 | 1/8" | 1/4" | 0.062" | 1/2" | 198 PSI |
| TSFE14-0250-047-50 | TSFE14-0250-047.10 | 5/32" | 1/4" | .047" | 1-21/64" | 145 PSI |
| TSFE14-0250-031-50 | - | 3/16" | 1/4" | .031" | 1" | 92 PSI |
| TSFE14-0312-062-50 | TSFE14-0312-062.10 | 3/16" | 5/16" | .062" | 1-1/2" | 155 PSI |
| TSFE14-0312-031-50 | TSFE14-0312-031.10 | 1/4" | 5/16" | .031" | 1-3/4" | 292 PSI |
| TSFE14-0375-062-50 | TSFE14-0375-062.10 | 1/4" | 3/8" | .062" | 1" | 127 PSI |
| TSFE14-0375-031-50 | TSFE14-0375-031.10 | 5/16" | 3/8" | .031" | 2-1/2" | 189 PSI |
| TSFE14-0500-062-50 | TSFE14-0500-062.10 | 3/8" | 1/2" | .062" | 3-31/32" | 92 PSI |
| TSFE14-0500-031-50 | TSFE14-0500-031.10 | 7/16" | 1/2" | .031" | 4" | 47 PSI |
| TSFE14-0625-062-50 | - | 1/2" | 5/8" | .062" | 3" | 72 PSI |
| TSFE14-0750-062-50 | TSFE14-0750-062.10 | 5/8" | 3/4" | .062" | 8-59/64" | 66 PSI |
How is this product sold?
No by the foot sales. This is a Packaged Length product.
6
Where can I find product documents?
Saint Gobain Versilon™ FEP Data Sheet
Consult product literature, manufacturer documentation, or supporting documents for additional information.
