TR4XF-16 Alfagomma by Kuriyama | TR4XF Series | SAE 100R4 | 4-Wire | Extra-Flexible Oil Return Hydraulic Hose | 1" ID | 1.42" OD | 250 PSI
If you are interested in this item please fill out the Contact Form below.
Contact Us
How can we help you?
Price, availability, and details—available upon request.
| Application: | Low pressure return lines or suction lines with half the bend radius requirements of SAE J517 100R4, service with petroleum based hydraulic fluids, water-glycol and water-fire resistant hydraulic fluids, oil, lubricants, crude oil, fuel oils and water. | SAE Rating: | Meets or exceeds SAE 100R4 |
|---|---|---|---|
| Other Ratings: | SAE J517 100R4, | Tube: | Black, conductive NBR. |
| Reinforcement: | Textile reinforced with four spiral wire helix to prevent collapsing. | Cover: | Black CR... oil, fuel, weather, ozone and abrasion-resistant. |
| Temperature Range: | -40°F (-40°C) to +212°F (+100°C) constant operation. Maximum Operating Temperature: +257°F (+125°C) |
Air Maximum Temperature: | +175°F (+80°C) Note: Operating temperatures in excess of +212°F (+100°C) may materially reduce the life of the hose. |
| Branding: | ALFAGOMMA - Italy - T634 (psi) - SAE 100R4 - (SIZE) - Date | ||
| Part Number | ID | OD | Max. Working Pressure* |
Min Bend Radius |
Weight | |||
|---|---|---|---|---|---|---|---|---|
| (in.) | (mm) | (in.) | (mm) | PSI | (in.) | (mm) | (lbs./ft.) | |
| TR4XF-12 | 3/4" | 19.1mm | 1.18" | 30.0mm | 300 PSI | 1.5" | 38.1mm | 0.41 lbs/ft |
| TR4XF-16 | 1" | 25.4mm | 1.42" | 36.0mm | 250 PSI | 2.0" | 50.8mm | 0.51 lbs/ft |
| TR4XF-20 | 1-1/4" | 31.8mm | 1.69" | 43.0mm | 200 PSI | 2.5" | 63.5mm | 0.62 lbs/ft |
| TR4XF-24 | 1-1/2" | 38.1mm | 1.93" | 49.0mm | 150 PSI | 3.0" | 76.2mm | 0.72 lbs/ft |
| TR4XF-32 | 2" | 50.8mm | 2.44" | 62.0mm | 100 PSI | 4.0" | 101.6mm | 0.93 lbs/ft |
| TR4XF-40 | 2-1/2" | 63.0mm | 2.99" | 76.0mm | 60 PSI | 4.9" | 125.0mm | 1.47 lbs/ft |
| TR4XF-48 | 3" | 76.0mm | 3.50" | 89.0mm | 60 PSI | 5.9" | 152.0mm | 1.75 lbs/ft |
* Minimum burst pressure 4-to-1 safety factor.
