T753AG100X50 Alfagomma by Kuriyama | 4- Ply Abrasive Material Blast Hose | Green | 1" ID | 1.89" OD | 150 PSI | 50ft Length

T753AG100X50 Alfagomma by Kuriyama | 4- Ply Abrasive Material Blast Hose | Green | 1" ID | 1.89" OD | 150 PSI | 50ft Length

Sale price$469.37

Kuriyama Alfagomma® T750AA / T750AG Series 150 PSI 4-Ply Abrasive Material Blast Hose - Green

Package Quantity: 50 FT

Buy More, Save More!
Quantity Price Each
5–14 $441.21
15–29 $398.96
30+ $352.03
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Alfagomma
Series:
  • T753AG Series
Color(s):
  • Black

SPECIFICATIONS

Application: Designed to convey abrasives, sand and shot blast material. SAE Rating: N/A
Other Ratings: N/A Tube: Black static conducting natural rubber - offering excellent abrasion resistance.
Reinforcement: High tensile textile cords - 4-ply construction. Cover: Green, conductive SBR/NR blend - abrasion and ozone resistant - pin pricked.
Temperature Range: -22 deg. F (-30 deg. C) to 176 deg. F (+80 deg. C) Crimp Fittings: N/A
Reusable Fittings: N/A Specifications N/A
Other Features:
  • Branding: ALFAGOMMA - ITALY T750 ABRASIVE MATERIAL BLAST - 10 BAR (150 PSI) O (in white letters)
  • COUPLING SUGGESTIONS: Sandblast couplings and nozzle holders attached with screws. See next column for coupling part numbers.
Part Number Color Nominal ID Nominal ID Tube Thickness Max Rec. Working Pressure Standard Length Weight
(in.) (mm) (in.) (mm) (mm) PSI (ft.) (lbs./ft.)
T753AG100X50 Green 1" 25mm 1.89" 48mm 0.283mm 150 PSI 50ft 1.04 lbs
NOTE: Tolerances according to RMA Class 311-A
Hose ID (in.) Hose Ends Nozzle Holders Threaded Female Adapter Gaskets
3/4 Q-1AL, Q-1BR, Q-1PI NH-1AL, NH-1BR - SBG
1 Q-2AL, Q-2BR, Q-2PI NH-2AL, NH-2BR - SBG
1-1/4 Q-3AL, Q-3BR, Q-3PI NH-3AL, NH-3BR SB-1AL, SB-1BR SBG
1-1/2 Q-4AL, Q-4BR, Q-4PI NH-4AL, NH-4BR SB-2AL, SB-2BR SBG

Kuriyama

Located in Schaumburg, Illinois, Kuriyama of America has been eminently successful in developing and marketing a complete line of thermoplastic hose and accessories. Their expansive product line consist of thermoplastic, rubber and metal hose products, along with accessories including couplings and fittings.
