R18-03R Wilkerson by Dixon Valve | R18-Series | Compact Regulator | 3/8" Size | 165 SCFM | without Gauge | 0-125 PSI Adjusting Range

R18-03R Wilkerson by Dixon Valve | R18-Series | Compact Regulator | 3/8" Size | 165 SCFM | without Gauge | 0-125 PSI Adjusting Range

Sale price$79.99
Buy more, save moreDiscounts applied in cart/checkout.
Features:
  • Self-relieving standard.
  • Can be installed with the adjusting knob in any position.
  • To increase regulated pressure, pull adjusting knob up and turn clockwise, to reduce pressure, turn knob counter clockwise.
  • Two 1/4" NPT gauge ports located on the front and rear faces of the body; ports may be used as additional regulated ports or for pressure gauges.
  • Models supplied without gauge use a GC230 gauge.
Specifications:
  • FRL's are designed for air service only, unless otherwise indicated.
  • Maximum operating conditions: 300 PSIG (20.7 bar) and -13°F to 150°F (-25°C to 65.5°C)
  • SCFM ratings at 100 PSIG inlet pressure.
Dimensions:
Part Number
With Gauge		 Part Number
Without Gauge		 Size Flow (SCFM)
R18-02RG R18-02R 1/4" 148 SCFM
R18-03RG R18-03R 3/8" 165 SCFM
R18-04RG R18-04R 1/2" 165 SCFM

Additional Product Data:

Brand:
  • Wilkerson
Series:
  • R18 Series
