R03-02R Wilkerson by Dixon Valve | R03-Series | Miniature Regulator | without Gauge | 1/4" Size | 15 SCFM | 2-125 PSI Adjusting Range

R03-02R Wilkerson by Dixon Valve | R03-Series | Miniature Regulator | without Gauge | 1/4" Size | 15 SCFM | 2-125 PSI Adjusting Range

Sale price$42.10

Dixon Valve
Wilkerson | R03-Series | Miniature Regulator

For air service only.

2-125 PSI adjusting range.


In stock
Buy More, Save More!
Quantity Price Each
10–39 $39.57
40–79 $35.79
80+ $31.58
Discounts applied in cart/checkout.

Product Data:

Brand:
  • Wilkerson
Series:
  • R03 Series
Special Properties:
  • Mini/Micro Size
Features:
  • Balanced valve design.
  • Self-relieving standard.
  • Non-rising push/pull locking adjustment knob.
  • Two 1/8" NPT gauge ports standard on models without gauge, one 1/8" NPT gauge port standard on models with gauge - can be used for additional outlet ports.
  • Models supplied without a gauge use a GC620 gauge.
  • Panel mount nuts sold separately.
Specifications:
  • Maximum operating conditions: 300 PSIG (20.17 bar) and 32°F to 125°F (0°C to 52°C).
  • SCFM ratings at 100 PSIG inlet pressure.
Dimensions:
Part Number
with Gauge		 Part Number
without Gauge		 Size Flow (SCFM)
R03-01RG R03-01R 1/8" 13 SCFM
R03-02RG R03-02R 1/4" 15 SCFM

Dixon Valve & Coupling

Dixon, founded in 1916, is a premier manufacturer and supplier of hose couplings, valves, dry disconnects, swivels, and other fluid transfer and control products. Our global reach includes a wide range of products for numerous industries including petroleum exploration, refining, transportation, chemical processing, food and beverage, steel, fire protection, construction, mining, and manufacturing.
