MSA2525F Dixon Forged Aluminum 2-1/2" Storz x 2-1/2" NST(NH) Male Adapter - Old Part #: SZM2525F
Dixon Fire Fittings
Adapters - Storz x Male NST(NH) Rigid - Forged Aluminum
- Machined from forged 6061- T6 aluminum.
- Hardcoat anodized components per MIL-A-8625 Type III Class 1.
| Buy More, Save More! | |
| Quantity | Price Each |
| 5–19 | $128.23 |
| 20–59 | $115.96 |
| 60+ | $102.32 |
Discounts applied in cart/checkout.
Product Data:
Shape:
Straight
Ends Configuration:
Material(s):
| Part Number | Storz Size | Male NST(NH) Rigid Thread | Working Pressure | Old Part # | Weight (Lbs.) |
|---|---|---|---|---|---|
| MSA1515F | 1-1/2" | 1-1/2" | 150 PSI | - | 0.3000 |
| MSA2015F | 2" | 1-1/2" | 150 PSI | - | 0.8000 |
| MSA2525F | 2-1/2" | 2-1/2" | 150 PSI | SZM2525F | 1.1700 |
| MSA3025F | 3" | 2-1/2" | 150 PSI | - | 1.5710 |
| MSA4025F | 4" | 2-1/2" | 150 PSI | SZM4025F | 3.6700 |
| MSA4040F | 4" | 4" | 150 PSI | - | 3.0940 |
| MSA4045F | 4" | 4-1/2" | 150 PSI | - | 3.3300 |
| MSA5025F | 5" | 2-1/2" | 150 PSI | SZM5025F | 4.6900 |
| MSA5050F | 5" | 5" | 150 PSI | - | 3.9800 |
